15 Receiver connection

This page is a translated version
the translation is 100% complete.
MICROBEAST PLUS can work with a lot of different receiver types and radio brands,
especially with different types of radio signal protocols. Depending on which signal protocol
and receiver you intend to use, the wiring layout may vary. In the following you can
see all supported protocols and specific wiring schemes for each receiver type. Ensure
a tight fit of the connectors. The pin board of MICROBEAST PLUS is designed so
that the plugs firmly clamp each other when they are fully inserted. Anyhow, especially
when using a receiver with single wire output it is possible that connectors are plugged
in with no adjacent neighbors. Such plugs should additionally be secured against loosening.
