Summary of Contents for Progress PHP5325X

  • Page 1 User Manual Oven PHP5325X...

  • Page 2: Table Of Contents

    2 Progress CONTENTS Safety information Using the accessories Safety instructions Additional functions Product description Hints and tips Control panel Care and cleaning Before first use Troubleshooting Daily use Technical information Clock functions Energy efficiency Automatic programmes Subject to change without notice.

  • Page 3: Safety Instructions

    Progress 3 General Safety Only a qualified person must install this appliance and • replace the cable. Internally the appliance becomes hot when in operation. Do • not touch the heating elements that are in the appliance. Always use oven gloves to remove or put in accessories or ovenware.
  • Page 4 4 Progress Electrical connection WARNING! Risk of fire and WARNING! Risk of injury, burns electrical shock. and electrical shock or explosion. • All electrical connections should be made by a qualified electrician. • Use this appliance in a household only.
  • Page 5 Progress 5 • Use a deep pan for moist cakes. Fruit • Keep children away from the appliance juices cause stains that can be while the Pyrolytic cleaning is in permanent. operation. • This appliance is for cooking purposes The appliance becomes very hot and hot only.

  • Page 6: Product Description

    6 Progress • Before replacing the lamp, disconnect • Disconnect the appliance from the mains the appliance from the power supply. supply. • Only use lamps with the same • Cut off the mains cable and discard it. specifications. • Remove the door catch to prevent...

  • Page 7: Control Panel

    Progress 7 For cakes and biscuits. To bake and roast or as a pan to collect fat. Combi pan CONTROL PANEL Electronic programmer Use the sensor fields to operate the appliance. Sensor Function Description Field DISPLAY Shows the current settings of the appliance.
  • Page 8 8 Progress Sensor Function Description Field To confirm a selection or setting. OVEN LIGHT To activate or deactivate the oven lamp. CLOCK To set the clock functions. MINUTE MINDER To set the Minute Minder. Display A. Oven function symbol B. Temperature / time of day display C.

  • Page 9: Before First Use

    Progress 9 Heat up indicator Knob indication Function If you activate an oven function, the bars Double zone switch come on in the display. The bars show that the temperature in the appliance increases 1. Turn the knob to a necessary heat or decreases.

  • Page 10: Daily Use

    10 Progress Changing the time After the software version goes off, the display shows h and 12:00. You can change the time of day only when the appliance is off. 1. Touch to set the hours. 2. Touch Touch 3. Touch to set the minutes.
  • Page 11 Progress 11 Oven function Application Defrost To defrost frozen food. Bottom Heat To bake cakes with crispy bottom and to preserve food. ECO Roasting The ECO functions let you optimize the energy consump- tion during cooking. It is necessary to set the cooking time first.

  • Page 12: Clock Functions

    12 Progress CLOCK FUNCTIONS Clock functions table Clock function Application COUNT UP TIMER To set the count up, which shows how long the appliance operates. This function has no effect on the operation of the appliance. TIME OF DAY To show the time of day. To change the time of day, refer to "Setting the time".

  • Page 13: Automatic Programmes

    Progress 13 Setting the SET+GO and "00" flash in the display. 2. Use to set the MINUTE You can use the SET+GO function only when the DURATION is set. MINDER. First you set the seconds, then the minutes and the hours.
  • Page 14 14 Progress Programme number Programme name CHICKEN, WHOLE WHOLE FISH PIZZA QUICHE LORRAINE LEMON SPONGE CAKE CHEESE CAKE ROLLS FARMER BREAD DOUGH PROVING POTATO GRATIN LASAGNE CANNELLONI CONVENIENCE CAKE CONVENIENCE PIZZA CONVENIENCE POTATO TYPES Automatic programmes 1. Activate the appliance.

  • Page 15: Using The Accessories

    Progress 15 USING THE ACCESSORIES Wire shelf and the deep pan together: WARNING! Refer to Safety Push the deep pan between the guide bars chapters. of the shelf support and the wire shelf on Inserting the accessories the guide bars above.
  • Page 16 16 Progress The Function Lock prevents an accidental When the function operates, change of the oven function. you can change the time and temperature. 1. To activate the function activate the appliance. • To deactivate the function touch 2. Activate an oven function or setting.

  • Page 17: Hints And Tips

    Progress 17 Brightness of the display 3. Touch 4. Touch to change the value of There are two modes of display brightness: the setting. • Night brightness - when the appliance is 5. Touch deactivated, the brightness of the display is lower between 10 PM and 6 Automatic Switch-off •...
  • Page 18 18 Progress Heat Application Time Hints setting (min) 1 - 2 To solidify fluffy omelettes and 10 - 40 Cook with a lid on. baked eggs. 2 - 3 To simmer rice and milk-based 25 - 50 Add a minimum of two times as dishes, and to heat up ready- much liquid as rice.
  • Page 19 Progress 19 Baking results Possible cause Remedy The cake sinks and becomes The oven temperature is too The next time you bake, set a soggy, lumpy or streaky. high. slightly lower oven tempera- ture. The cake sinks and becomes The baking time is too short.
  • Page 20 20 Progress Food Function Temperature Time (min) Shelf position (°C) Flan base - True Fan 150 - 170 20 - 25 sponge mixture Cooking Apple pie / Ap- True Fan 60 - 90 ple pie (2 tins Cooking Ø20 cm, diago-...
  • Page 21 Progress 21 Food Function Temperature Time (min) Shelf position (°C) Fruit flans True Fan Cook- 35 - 55 (made with yeast dough / sponge mix- ture) Fruit flans Conventional 35 - 55 (made with Cooking yeast dough / sponge mix-...
  • Page 22 22 Progress Food Function Temperature Time (min) Shelf position (°C) Biscuits made True Fan Cook- 150 - 160 20 - 40 with yeast dough Puff pastries True Fan Cook- 20 - 30 170 - 180 Rolls True Fan Cook- 10 - 25...
  • Page 23 Progress 23 Multilevel Baking Use the function True Fan Cooking. Cakes / pastries / breads on baking trays Food Temperature Time (min) Shelf position (°C) 2 positions 3 positions Cream puffs / 25 - 45 1 / 4 160 - 180...
  • Page 24 24 Progress The default is 90 °C. After the temperature 2. Put the meat together with the hot is set, the oven continues to cook at 80 °C. roasting pan into the oven on the wire Do not use this function for poultry.
  • Page 25 Progress 25 Food Temperature (°C) Time (min) Shelf position Piroggen (Russian 15 - 25 180 - 200 version of calzone) 1) Preheat the oven. 2) Use a deep pan. Roasting • To prevent the meat juices or fat from burning onto the pan, put some liquid •...
  • Page 26 26 Progress Pork Food Quantity Function Tempera- Time (min) Shelf po- ture (°C) sition Shoulder / 1 - 1.5 kg Turbo Grill- 160 - 180 90 - 120 Neck / Ham joint Chop / Spare 1 - 1.5 kg Turbo Grill-...
  • Page 27 Progress 27 Poultry Food Quantity Function Tempera- Time (min) Shelf posi- ture (°C) tion Poultry por- 200 - 250 g Turbo Grill- 200 - 220 30 - 50 tions each Half chicken 400 - 500 g Turbo Grill- 190 - 210...
  • Page 28 28 Progress Food Temperature Time (min) Shelf position (°C) 1st side 2nd side Whole Fish, 500 210 - 230 15 - 30 15 - 30 3 / 4 - 1000 g Fast Grilling Food Time (min) Shelf position 1st side...
  • Page 29 Progress 29 Frozen ready meals Food Function Temperature Time (min) Temperature (°C) (°C) Frozen pizza Conventional as per manu- as per manu- Cooking facturer’s in- facturer’s in- structions structions Conventional 200 - 220 as per manu- French fries Cooking or Tur- facturer’s in-...
  • Page 30 30 Progress Preserving - Bottom Heat • The jars cannot touch each other. • Put approximately 1/2 litre of water into • Use only preserve jars of the same the baking tray to give sufficient moisture dimensions available on the market.

  • Page 31: Care And Cleaning

    Progress 31 Vegetables Food Temperature Time (h) Shelf position (°C) 1 position 2 positions Beans 60 - 70 6 - 8 1 / 4 Peppers 60 - 70 5 - 6 1 / 4 Vegetables for 60 - 70 5 - 6...
  • Page 32 32 Progress 4. Touch to set the duration of the cleaning procedure: Option Description 1:00 h for a low degree of dirt 1:30 h for a usual degree of dirt 2:30 h for a high Install the shelf supports in the opposite degree of dirt sequence.

  • Page 33: Troubleshooting

    Progress 33 9. Clean the glass panel with water and soap. Dry the glass panel carefully. When the cleaning is completed, install the glass panels and the door. Do the above steps in the opposite sequence. Install the smaller panel first, then the larger.
  • Page 34 34 Progress What to do if... Problem Possible cause Remedy The cooking zones do not Refer to the operating instructions for the built-in cooking sur- operate. face. You cannot activate or oper- The oven is not connected to Check if the oven is correctly ate the oven.

  • Page 35: Technical Information

    Progress 35 Problem Possible cause Remedy The display shows "F102". • You did not fully close the • Fully close the door. door. • Deactivate the oven with • The door lock is defective. the house fuse or the safety switch in the fuse box and activate it again.
  • Page 36 36 Progress Model identification PHP5325X Energy Efficiency Index 103.5 Energy efficiency class Energy consumption with a standard load, conventional 0.99 kWh/cycle mode Energy consumption with a standard load, fan-forced 0.88 kWh/cycle mode Number of cavities Heat source Electricity Volume 71 l...
  • Page 37 Progress 37 ENVIRONMENT CONCERNS dispose appliances marked with the symbol Recycle the materials with the symbol with the household waste. Return the Put the packaging in applicable containers product to your local recycling facility or to recycle it. Help protect the environment contact your municipal office.
  • Page 38 38 Progress...
  • Page 39 Progress 39...
  • Page 40 867309485-B-362015...
