Table 11 Pin Out Description - Portwell COM Express PCOM-B700G User Manual

COM Express™
D101 PCIE_TX31+
D102 PCIE_TX31-
D103 GND
D104 VCC_12V
D105 VCC_12V
D106 VCC_12V
D107 VCC_12V
D108 VCC_12V
D109 VCC_12V
D110 GND(FIXED)
Copyright © PORTWELL 2018
PCI Express Differential Transmit
Pairs
PCI Express Differential Transmit
Pairs
GND
Primary power input: +12V
nominal.
Primary power input: +12V
nominal.
Primary power input: +12V
nominal.
Primary power input: +12V
nominal.
Primary power input: +12V
nominal.
Primary power input: +12V
nominal.
GND(FIXED)

Table 11 Pin out description

PORTWELL PCOM-B700G User's Guide
O PCIE AC coupled on Module
O PCIE AC coupled on Module
- - -
- PWR +12V
- PWR +12V
- PWR +12V
- PWR +12V
- PWR +12V
- PWR +12V
- - -
PCOM-B700G User's Guide
- -
- -
- -
- -
- -
- -
- -
- -
- -
- -
68
