COM Express™
A10
GBE0_MDI1+
A11
GND(FIXED)
A12
GBE0_MDI0-
A13
GBE0_MDI0+
A14
GBE0_CTREF
A15
SUS_S3#
A16
SATA0_TX+
A17
SATA0_TX-
A18
SUS_S4#
A19
SATA0_RX+
Copyright © PORTWELL 2018
Gigabit Ethernet Controller 0:
Media Dependent Interface
Differential Pairs
GND(FIXED)
Gigabit Ethernet Controller 0:
Media Dependent Interface
Differential Pairs
Gigabit Ethernet Controller 0:
Media Dependent Interface
Differential Pairs
Reference voltage for Carrier
Board Ethernet channel 0
magnetics center tap.
Indicates system is in Suspend to
RAM state. Active low output. An
inverted copy of SUS_S3# on the
Carrier Board may be used to
enable the non-standby power on
a typical ATX supply.
Serial ATA or SAS Channel 0
transmit differential pair.
Serial ATA or SAS Channel 0
transmit differential pair.
Indicates system is in Suspend to
Disk state. Active low output.
Serial ATA or SAS Channel 0
receive differential pair.
PORTWELL PCOM-B700G User's Guide
I/O
Analog
3.3V max Suspend
-
-
-
I/O
Analog
3.3V max Suspend
I/O
Analog
3.3V max Suspend
-
-
GND min 3.3V max
O
CMOS
3.3V Suspend / 3.3V
O
SATA
AC coupled on Module
O
SATA
AC coupled on Module
O
CMOS
3.3V Suspend / 3.3V
I
SATA
AC coupled on Module
PCOM-B700G User's Guide
-
-
-
-
-
-
-
-
Placeholder
0 ohm to
-
V_1P5_L1
PD 10kohm
-
-
-
-
-
-
-
-
-
31
