Portwell COM Express PCOM-B700G User Manual page 52

COM Express™
C19 PCIE_RX6+
C20 PCIE_RX6-
C21 GND(FIXED)
C22 PCIE_RX7+
C23 PCIE_RX7-
C24 10G_INT2
C25 GND
C26 10G_KR_RX3+
C27 10G_KR_RX3-
C28 GND
C29 10G_KR_RX2+
C30 10G_KR_RX2-
C31 GND(FIXED)
C32 10G_SFP_SDA3
Copyright © PORTWELL 2018
PCI Express Differential Receive
Pairs
PCI Express Differential Receive
Pairs
GND(FIXED)
PCI Express Differential Receive
Pairs
PCI Express Differential Receive
Pairs
Interrupt pin from copper PHY or
optical SFP Module to the 10GbE
controller
GND
10GBASE-KR ports, receive input
differential pairs.
10GBASE-KR ports, receive input
differential pairs.
GND
10GBASE-KR ports, receive input
differential pairs.
10GBASE-KR ports, receive input
differential pairs.
GND(FIXED)
I2C data signal of the 2-wire
management interface used by the
10GbE controller to access the
management registers of an
PORTWELL PCOM-B700G User's Guide
I PCIE AC coupled off Module
I PCIE AC coupled off Module
- - -
I PCIE AC coupled off Module
I PCIE AC coupled off Module
I - 3.3V Suspend / 3.3V
- - -
AC coupled on
I KR
Module
AC coupled on
I KR
Module
- - -
AC coupled on
I KR
Module
AC coupled on
I KR
Module
- - -
I/O OD 3.3V Suspend / 3.3V
PCOM-B700G User's Guide
- -
- -
- -
- -
- -
- -
- -
- -
- -
- -
- -
- -
- -
- -
52
