COM Express™
B109 VCC_12V
B110 GND(FIXED)
C1 GND(FIXED)
C2 GND
C3 USB_SSRX0-
C4 USB_SSRX0+
C5 GND
C6 USB_SSRX1-
C7 USB_SSRX1+
C8 GND
C9 USB_SSRX2-
C10 USB_SSRX2+
C11 GND(FIXED)
Copyright © PORTWELL 2018
Primary power input: +12V
nominal.
GND(FIXED)
GND(FIXED)
GND
Additional transmit signal
differential pairs for the
SuperSpeed USB data path.
Additional transmit signal
differential pairs for the
SuperSpeed USB data path.
GND
Additional transmit signal
differential pairs for the
SuperSpeed USB data path.
Additional transmit signal
differential pairs for the
SuperSpeed USB data path.
GND
Additional transmit signal
differential pairs for the
SuperSpeed USB data path.
Additional transmit signal
differential pairs for the
SuperSpeed USB data path.
PORTWELL PCOM-B700G User's Guide
- PWR +12V
- - -
- - -
- - -
I PCIE AC coupled off Module
I PCIE AC coupled off Module
- - -
I PCIE AC coupled off Module
I PCIE AC coupled off Module
- - -
I PCIE AC coupled off Module
I PCIE AC coupled off Module
