COM Express™
B25 PCIE_RX14+
B26 PCIE_RX14-
B27 WDT
B28 RSVD
B29 RSVD
B30 RSVD
B31 GND(FIXED)
B32 SPKR
B33 I2C_CK
B34 I2C_DAT
B35 THRM#
B36 PCIE_RX13+
B37 PCIE_RX13-
Copyright © PORTWELL 2018
other configurable devices time to
be programmed.
PCI Express Differential Receive
Pairs
PCI Express Differential Receive
Pairs
Output indicating that a watchdog
time-out event has occurred.
Reserved Pin
Reserved Pin
Reserved Pin
GND(FIXED)
Output for audio enunciator
General purpose I2C port clock
output
General purpose I2C port data I/O
line
Input from off-Module temp sensor
indicating an over-temp situation
PCI Express Differential Receive
Pairs
PCI Express Differential Receive
Pairs
PORTWELL PCOM-B700G User's Guide
I PCIE AC coupled off Module
I PCIE AC coupled off Module
O CMOS 3.3V / 3.3V
- - -
- - -
- - -
- - -
O CMOS 3.3V / 3.3V
I/O CMOS 3.3V Suspend / 3.3V
I/O CMOS 3.3V Suspend / 3.3V
I CMOS 3.3V / 3.3V
I PCIE AC coupled off Module
I PCIE AC coupled off Module
PCOM-B700G User's Guide
- -
- -
- -
- -
- -
- -
- -
- -
PU 2.2k
-
ohm to 3.3V
PU 2.2k
-
ohm to 3.3V
PU 1k ohm
-
to 3VSB
- -
- -
