COM Express™
D7 USB_SSTX1+
D8 GND
D9 USB_SSTX2-
D10 USB_SSTX2+
D11 GND(FIXED)
D12 USB_SSTX3-
D13 USB_SSTX3+
D14 GND
D15 10G_PHY_MDIO_SDA3
Copyright © PORTWELL 2018
Additional transmit signal
differential pairs for the
SuperSpeed USB data path.
GND
Additional transmit signal
differential pairs for the
SuperSpeed USB data path.
Additional transmit signal
differential pairs for the
SuperSpeed USB data path.
GND(FIXED)
Additional transmit signal
differential pairs for the
SuperSpeed USB data path.
Additional transmit signal
differential pairs for the
SuperSpeed USB data path.
GND
MDIO Mode: Management Data
I/O interface mode data signal for
serial data transfers between the
MAC and an external PHY.
I2C Mode: I2C data signal, of the
2-wire management interface used
for serial data transfers between
the MAC and an external PHY.
PORTWELL PCOM-B700G User's Guide
O PCIE AC coupled on Module
- - -
O PCIE AC coupled on Module
O PCIE AC coupled on Module
- - -
O PCIE AC coupled on Module
O PCIE AC coupled on Module
- - -
O - 3.3V Suspend / 3.3V
I/O OD - 3.3V Suspend / 3.3V
