COM Express™

3.6 3 SODIMM socket design

PCOM-B700G has designed additional Memory SODIMM socket at the bottom, which supports up to DDR4 48GB capacity. Before
inserting the DDR4 SODIMM memory, please refer to below SODIMM arrangement and note that, there are 2 SODIMM socket of
channel 0, the CH0 SODIMM1 (the bottom one) works only if CH0 SDDIMM0 (the top one) is inserted.

3.7 Environmental Specifications

Storage Temperature
Operation Temperature
Storage Humidity
Operation Humidity

3.8 Ordering Guide

PCOM-B700GVG
Product
PCOM-B700G-D1507
PCOM-B700G-D1508
PCOM-B700G-D1517
Copyright © PORTWELL 2018
-20°C ~85°C
0°C ~60°C
Extended : -40°C ~+85°C (Processor dependent)
0%~95%
0%~95%

Table 7 Environmental Specifications

Ordering P/N
AB1-3G79
AB1-3G78
AB1-3G77
PCOM-B700G User's Guide
PORTWELL PCOM-B700G User's Guide
Status
Available
Available
Available
25
