COM Express™
B15
SMB_ALERT#
B16
SATA1_TX+
B17
SATA1_TX-
SUS_STAT# /
B18
ESPI_RESET#
B19
SATA1_RX+
B20
SATA1_RX-
B21
GND(FIXED)
B22
PCIE_RX15+
B23
PCIE_RX15-
B24
PWR_OK
Copyright © PORTWELL 2018
System Management Bus Alert –
active low input can be used to
generate an SMI# (System
Management Interrupt) or to wake
the system.
Serial ATA or SAS Channel 1
transmit differential pair.
Serial ATA or SAS Channel 1
transmit differential pair.
Indicates imminent suspend
operation; used to notify LPC
devices / Shared pin with
ESPI_RESET
Serial ATA or SAS Channel 1
receive differential pair.
Serial ATA or SAS Channel 1
receive differential pair.
GND(FIXED)
PCI Express Differential Receive
Pairs
PCI Express Differential Receive
Pairs
Power OK from main power
supply. A high value indicates that
the power is good. This signal can
be used to hold off Module startup
to allow carrier based FPGAs or
PORTWELL PCOM-B700G User's Guide
I
CMOS
3.3V Suspend / 3.3V
O
SATA
AC coupled on Module
O
SATA
AC coupled on Module
O
CMOS
3.3V Suspend / 3.3V
I
SATA
AC coupled on Module
I
SATA
AC coupled on Module
-
-
-
I
PCIE
AC coupled off Module
I
PCIE
AC coupled off Module
I
CMOS
3.3V / 3.3V
PCOM-B700G User's Guide
PU 4.7k
ohm to
-
3VSB
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
41
