1.5 Water circuit – description
Water circuit will be constructed with respect to the
applicable norms and requirements.
Please see the specifications in sections 3.1. and 3.2
1.5.1 Requirements for the water circuit
Depending upon the materials used in the water circuit of
the dwelling, incorrect material combinations can lead to
corrosion damage due to galvanic corrosion.
This requires special attention with the use of galvanised
components and components that contain copper
1.5.2 Dimensions
Vanvex R:
1.
Supply air
2.
Exhaust air
3.
Circuit board
4.
Condensate drain
5.
Compressor
6.
Magnetic valve
7.
Non return valve
8.
285 liter boiler
9.
Service connecting
10.
1,5 kW electric heating element
11.
Anode
12.
Cold water connecting 3/4" AG
13.
Hot water circulation 3/4" AG
14.
Hot water connecting contact 3/4" AG
15.
High pressure switch
- The right to make changs is reserved -
Installation Manual
Ø 660
A
14
13
12
A
1
5
12
10
9
8
SECTION A-A
2
4
15
6
7
3
5
