Installation Manual
1.5.3 Water circuit – hydraulics diagram
8
8
1 - Main valve
2 - Reducing valve
3 - Test valve
4 - Contra valve
5 - Manometer adapter
6 - Circulation pump
7 – Screwed connection with coupling
8 – ¾"
• Drinking water filter (DIN 1988) in hose service
connection
• Safety valve (p = 6 bar) to be mounted above
the edge of the tank
• Valve at the lowest point for draining
6
7
varmt vand
warm water
Warmwasser
8
cirkulation
circulation
Zirkulation
7
til sikkerhedsventil
to safety valve
nach Sicherheitsventil
tilslutning koldt vand
cold water connection
Kaltwasseranschluss
7
tømning
draining
Entleerung
- The right to make changs is reserved -
