Programming A User Pin - Simons Voss Technologies PinCode keypad Quick Manual

PinCode keypad (offline)
NOTE
The Master PIN is essential to use the PIN code keypad and cannot be
imported, read or regenerated. Make a note of the Master PIN and keep
it in a safe, secret place.
The Master PIN can be changed at any time. No programming is re-
quired to make a change.

4.2 Programming a user PIN

Up to three User PINs can be issued in the PIN code keypad. The User
PIN may consist of between 4 and 8 digits, which must not be
consecutive or identical.
An aid to better understanding: Each User PIN behaves as a separate
transponder. As a result, these individual User PINs must be
programmed in the respective (internal) transponders (1, 2 & 3).
1. Enter 0
2. Enter Master PIN
3. Enter User PIN – e.g. 1 for User PIN 1
4. Enter the length of the User PIN – e.g. 4 for a 4-digit User PIN
5. Enter User PIN
Repeat the process to programme otherUser PINs into the PIN code
keypad.
EN
4. Configuration
25 / 104
