9
With the nozzles facing down and the metal contacts
toward the back, insert the Printhead into the Carriage .
Carefully push the printhead fi rmly into the Carriage ,
ensuring that the nozzles and metal contacts do not touch
the carriage.
10
Pull the Printhead Fixer Cover down toward the front to
lock the Printhead in place.
11
Push the Printhead Fixer Lever toward the back of the
printer until it clicks.
12
Close the Top Cover .
It takes about six minutes for ink to fi ll the system.
• Never remove an Ink Tank while the system is fi lling with ink.
• If Auto Print is set to On in the printer menu, the printhead will be automatically adjusted after
Printhead replacement when the system is fi nished fi lling with ink. In this case, follow the instructions
displayed for Printhead adjustment. If Auto Print is set to Off , execute Auto Head Adj. > Advanced
Adj. in the printer menu. (→ , If Vertical Lines are Warped or Colors are Misaligned)
41
Replacing the Printhead
