8
Press the OK button.
The printer now initializes the Maintenance Cartridge .
Next, replace the Shaft Cleaner .
Replace the shaft cleaner
1
After the message is displayed regarding Shaft Cleaner
replacement, press ▲ or ▼ to select Yes , and then press
the OK button.
After the Carriage is moved, the Display Screen indicates
Open Upper Cover .
• If you do not respond within two minutes, shaft cleaner replacement is canceled and the printer goes
online automatically. If the printer is online, execute Repl. S. Cleaner in the MAIN MENU .
2
Open the Top Cover .
• Do not open the Printhead Fixer Lever toward the front.
Accidentally opening the Printhead Fixer Lever toward
the front will draw out ink, which consumes ink.
3
Hold the Shaft Cleaner on the right side of the Carriage
by the grips (a) and pull it toward you to remove it.
35
Replacing the Maintenance Cartridge
OK
a
