Gilson Safe Aspiration Quick Manual

Quick Guide
EN | FR
Parts Checklist
COMPONENT
1
Aspiration hand operator
Silicon adapter for Pasteur pipette (already
not pictured
mounted under the bayonet cap)
Safety stand for the hand operator with storing
2
gaps for the adapters
3 Single-channel plastic tip adapter with ejector
8-channel plastic tip adapter with ejector
4
5 8-channel stainless steel needle adapter
Four single-channel stainless steel needle adapters
(various sizes):
• 4 cm length, 1.5 mm diameter
6
• 4 cm length, 3 mm diameter
• 12 cm length, 1.5 mm diameter
• 12 cm length, 3 mm diameter
not pictured Silicon adapter for Pasteur pipette
not pictured Silicon grease
3
5
4
2
Image 1
Safe Aspiration Kit components
Composants du Safe Aspiration Kit
1
6
KIT
MATERIAL
Delrin® acetal resin and silicon
Silicon
Delrin acetal resin
Delrin acetal resin
Delrin acetal resin
Delrin acetal resin and stainless steel
Delrin acetal resin and stainless steel
Silicon
Silicon
A
Image 2
Installation steps
Etapes d'installation
C
1
B
