Gilson SGA-5R Service Manual

Motor Replacement Instructions for

DISASSEMBLY OF OLD MOTOR

1. Unplug unit, remove both threaded
2. Flip unit over.
3. Remove the (4) 1/4" x 20 Nylon Insert
4. Pull case up and tilt to the left. Be careful
5. Remove the green ground wire from the
PHONE: 800-444-1508
740-548-7298
SGA-5R & SGA-5RT
rods.
Lock-Nuts.
not to pull on ground wire lead.
perforated metal bracket. Remove both
black motor lead wires. Be careful not
to pull wires out of the connectors. Cut
the plastic zip ties holding the wires to
the inside case for easier disconnection.
E-mail: customerservice@gilsonco.com
P.O. Box 200, Lewis Center, Ohio 43035-0200
Product Web Page:
6. Remove both weights. Note the orienta-
tion of the weight on each motor shaft
for re-assembly. See below for Model
Number:
SGA-5R
7. Remove the two machine screws and
washers from right side perforated
metal bracket.
8. Remove three nuts, lock washers and
flat washers from motor studs and slide
bracket off.
9. Remove the four nuts, lock washers
and flat washers from the peforated
metal bracket from the opposite side
of motor.
10. Remove motor. NOTE: Do not transfer
the nuts on motor studs. Discard with
motor.
www.globalgilson.com
SGA-5RT
Rev: 01/2019
FAX: 800-255-5314
740-548-5314
