- Page 1 OPERATING MANUAL Vibro-Deairator SGA-5R & SGA-5RT Rev: 02/01/2013 PHONE: 800-444-1508 FAX: P.O. Box 200, Lewis Center, Ohio 43035-0200 800-255-5314 740-548-7298 E-mail: customerservice@gilsonco.com Website: www.globalgilson.com 740-548-5314...
-
Page 2: Safety Instructions
Gilson Company, Inc. Vibro-Deairator: SGA-5R & SGA-5RT SAFETY INSTRUCTIONS Whether you are the owner, employer, operator, or maintenance person for this machine, safety is your responsibil- ity. You are responsible for operating and maintaining this equipment in compliance with these instructions and for using common sense. -
Page 3: Table Of Contents
Gilson Company, Inc. Vibro-Deairator: SGA-5R & SGA-5RT Table of Contents Page Safety Instructions Table of Contents Introduction Unpacking & Assembly Set-Up Glass Filter-Flasks Aluminum Pycnometers SG-15 Plastic Pycnometer Operating Instructions Diagrams Figure 1: Glass Filter-Flask Figure 2: Aluminum Pycnometer Figure 3: Plastic Pycnometer... -
Page 4: Introduction
GW-75, and 4L GW-76), Aluminum Pycnometers (Gilson base plate and use two 9/16in wrenches to tighten the nuts 2,000g SG-16, and 1,500g SG-17), and the Gilson 6,000g and secure the rod. Repeat for the opposite side. SG-15 Plastic Pycnometer. -
Page 5: Sg-15 Plastic Pycnometer
SGA-15 on the ring. The upper adapter of the This unit is equipped with an easy-to-operate Gilson SGA-7 is placed with the foam side down on top of the pycnometer. Slide the top plate over the adjustment rods interval count-down timer. -
Page 6: Diagrams
Gilson Company, Inc. Vibro-Deairator: SGA-5R & SGA-5RT 5.0 PARTS DIAGRAMS: 5.1 Figure 1: Glass Filter-Flask SGA-8 Top Adapter Speed Knob Top Plate Threaded Knob Adjustment Rod SGA-8 Rubber Base Pad Base Plate ON/OFF/Timed Operation Switch Vibration Control Timer/Controller Figure 1... - Page 7 Gilson Company, Inc. Vibro-Deairator: SGA-5R & SGA-5RT 5.2 Figure 2: Aluminum Pycnometer Top Plate Speed Knob Threaded Knob SG-16 or SG-17 Aluminum Pycnometer (No Adapter Required) Adjustment Rod ON/OFF/Timed Operation Switch Base Plate Vibration Control Timer/Controller Figure 2 Using SG-16 or SG-17 Aluminum Pycnometer...
- Page 8 Gilson Company, Inc. Vibro-Deairator: SGA-5R & SGA-5RT 5.3 Figure 3: Plastic Pycnometer SGA-7 Upper Adapter Speed Knob Top Plate Threaded Knob SG-15 Plastic Pycnometer Adjustment Rod Base Plate ON/OFF/Timed Operation Switch SGA-7 Adapter Ring Timer/Controller Vibration Control Figure 3 Using SG-15 Plastic Pycnometer...
-
Page 9: Additional Information
Gilson Interval Countdown Timer 6.0 ADDITIONAL INFORMATION: VIBRO-DEAIRATOR ASTM D 2041; AASHTO T 209 other containers. Special SGA-5RT has modified vibration Test and other specific gravity determinations. characteristics to meet the requirements of Texas DOT. vibration control allows for setting optimum Special "speed knobs"...
