- Page 1 Boost Your Bars User Manual F20GI-5S-IoT F20G-5S-IoT Mobile Signal Booster...
-
Page 2: Table Of Contents
CONTENT WHAT'S INCLUDED HOW IT WORKS HOW TO INSTALL YOUR SIGNAL BOOSTER 1.1 Overview 1.2 Booster System Installation Examples 1.3 Installation Preparation 1.4 How to find the location with the strongest received signal 1.5 Install Outdoor Antenna 1.6 Install Indoor Antenna 1.7 Install Signal Booster 1.8 Run coaxial cable 1.9 Power up your the Signal Booster... -
Page 3: What's Included
3/20... -
Page 4: How It Works
HOW IT WORKS The HiBoost Home Plus signal booster is designed to help mobile users improve signal in homes, offices, and other areas where cellular signal is weak or unreliable. The outdoor antenna receives the signal from the nearest cellular tower, amplifies it, and transmits to the signal booster. Then the indoor antenna will receive the signal and retransmit it to your mobile device. -
Page 5: Installation Preparation
1-Outdoor wide band Directional antenna 2-50ft (15.2m) Hiboost200 low-loss cable 3- You can add an indoor panel/omni antenna and 50ft (15.2m) Hiboost200 low-loss cable to extend the coverage 1- 0utdoor Wide Band Directional Antenna 2- 50ft (15.2m) Hiboost200 Low-loss Cable 3- You can add an indoor panel/omni antenna with SMA-N connector to connect 50ft (15.2m) Hiboost200 low-loss cable to extend the coverage (built-in antenna will be automatically disabled) -
Page 6: How To Find The Location With The Strongest Received Signal
Tools Required Phillips Screwdriver Drill Mobile Phone Before you get started, you will need to plan the layout of your system. This involves finding the location with the strongest received signal from the cellular tower, as well as antenna, booster, and cable placement. - Page 7 antenna on the roof of the building and point it to the nearest cell tower. Then have a look at the gain and output power value displayed on the booster's LCD. Note: Above values displayed on the LCD are examples for Home 10K Plus, other models please refer to the data sheet.
-
Page 8: Install Outdoor Antenna
Note: Please try to receive a signal from cell towers that are not overloaded with multiple users. This can be estimated by the population density in the area served by the tower. For example, it is recommended to avoid cell towers near supermarkets, shopping malls, stadiums or any other public places visited by many people regularly. -
Page 9: Install Signal Booster
1.7 Install your signal booster The signal booster should be mounted in an easily accessible area so it's easy to perform general maintenance. The area is properly ventilated and not exposed to excessive heat, moisture and/or direct sunlight. The optimal area would be on a wall located near a power outlet. -
Page 10: Power Up Your The Signal Booster
•Keep horizontal cables straight and fasten them with a tie every three to five feet. •Bind and fasten vertical cables every six to eight feet. •Waterproof all connectors between outdoor antenna and coaxial cables with waterproof tape to avoid water or other kinds of damage. •Be careful when plugging the connector in so as not to damage the center pins on the connectors. -
Page 11: Booster Ports'description
·Booster Ports’ Description 1.LCD 2.LED indicators 3.Control buttons 4.Indoor antenna 5.In-built antenna port 6.USB 7.Power 8.Outdoor antenna port 9.Wifi led 10.Bluetooth led ·LCD Features Note: Above values displayed on the LCD are examples for Home 1 OK Plus, other models please refer to the data sheet. - Page 12 display "ISO" value showing the current band or bands affected. ALC: When the booster is receiving too much DL power from the tower and the DL booster output is close to saturating, the "ALC" indicators will flash showing that the ALC has lowered the gain to prevent this overload condition.
-
Page 13: Led Status
·LED Status Status Definition Green Normal Power LED Off DC power problem Check coverage, leave as is if it's Output power is good; if the coverage is poor, Green not maximum. please check the Troubleshoot- ing section to get solutions. Slow Flashing- Full output power. -
Page 14: Control Buttons Operation And Manual Gain Control (Mgc)
Control Buttons Operation and Manual gain control (MGC) There are 5 operation modes relative to the control keys: • Press the "SET" key for more than 3 seconds • Short press on the "SET" key • Short press on the "DEC-" key •... -
Page 15: Troubleshooting
switch to different pages. If none of the keys are pushed within 30 seconds, the display will return to the fixed display mode. If none of the control keys are pushed within 5 minutes, the LCD screen will turn off. Pressing any key will return the display to the fixed mode. -
Page 16: Authorized Kitting Options
direction or position of the outdoor antenna. You may also try replacing the outdoor antenna with a higher gain antenna to increase the incoming signal. • Check to see if it is necessary to add more indoor antennas. Barriers such as walls can block the signal indoors. -
Page 17: Fcc Rf Exposure Statement
FCC RF EXPOSURE STATEMENT This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environ- ment. End users must follow the specific operating instruction for satisfying RF exposure compliance. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.This equipment should be installed andoperated with minimum distance 20cm between the radiator&... - Page 18 • Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by HiBoost could void the user's authority to operate the equipment. Note: For a complete list of antennas and cables approved for use with these boosters see Authorized Kitting Options page 16.
-
Page 19: Specification
FURTHER INFORMATION ON SIGNAL BOOSTER END-USE REGISTRATION The following links are the currently active contacts for booster registration with U.S. wireless providers. https://www.uscellular.com/uscellular/support/fcc-booster-registration.jsp https://www.sprint.com/legal/fcc_boosters.htmI https://www.verizonwireless.com/solutions-and-services/accessories/register-signal-booster/ https://support.t-mobile.com/docs/DOC-9827 https://securec45.securewebsession.com/attsignalbooster.com/ ISEDC Statement This device complies with Innovation, Science, and Economic Development Canada licence RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. - Page 20 20/20...
-
Page 21: Product Warranty
Returned Material Authorization (RMA) number supplied by HiBoost. HiBoost will supply two options: repair or replace. HiBoost will cover the cost of delivery for the consumers located within the continental U.S. This warranty does not apply to any signal boosters or kits determined by HiBoost to have been subjected to misuse, abuse, neglect, or mishandling that alters or damages physical or electronic properties.
