Table Of Contents - SMC Networks CS2 Operation Manual

Contents
1. Safety Instructions
2. Product specifications
1) Specifications
2) Max. stroke
3) Max. usable stroke by the side load given to the cylinder
4) The relation between cylinder size and max. stroke by the mounting style
5) Theoretical output
6) Kinetic energy absorbed by cushion mechanism
7) How to order
3. Mounting, Operation
1) Operating air
2) Precaution on design
3) Mounting
4) Operating environment
5) Piping
6) Cushion
7) Speed control
8) Direction control
4. Maintenance
1) Inspection
2) Overhaul
3) Disassembly
4) Assembly
5) Expendable supplies
6) Replacement procedure of seal
7) Inspection
5. Troubleshooting
6. Construction
7. Auto switch precautions
1) Applicable auto switches
2) Precautions for use
-1-
付表 3 2/5
P.2
P.4
P.4
P.5
P.5
P.7
P.9
P.9
P.10
P.10
P.10
P.11
P.13
P.13
P.14
P.15
P.16
P.16
P.17
P.17
P.18
P.18
P.19
P.20
P.21
P.22
P.23
P.26
P.30
P.30
P.32
