IndraControl XFE 01.1 Extension Mod-
ules Profibus, RT-Ethernet, Sercos, CAN

2 Product identification and scope of delivery

2.1 Product identification and type plate

1
MNR: R911172531 -AA0
17
FW: 101
16
15
14
13
12
"IND.CONT.EQ"
32FB
2700729
1 Word mark
2 Part number
3 Device name
4 State of revision
5 Functional index
6 Plant number
7 Serial number
8 Serial number as barcode
9 Date of manufacture (yyWww)
Fig. 2-1: Exemplary type plate

2.2 Scope of delivery

Extension module
●
Bus base
●
24 V power connector XA-CN01
●
Product identification and scope of delivery
2 3 4 5 6
IndraControl XFE
7260
FI: 001
Bosch Rexroth AG, Bgm.-Dr.-Nebel-Str. 2
DE-97816 Lohr Hotline: +49 9352 405060
Made in Germany
U DC 24 V
N
I 0.6 A
N
I-V-C-B-T-V
11
16 channels
Wire Range 24-16
7 8
SN: 7260007123456BC
CERTIFIED
18
10 CE conformity marking
11 Company address
12 Underwriters Laboratories Inc. mark
13 Check digit
14 Nominal current
15 Nominal voltage
16 Manufacturing country
17 Software release
18 QR code
R911345570_Edition 05 Bosch Rexroth AG
3/31
9
FD: 12W16
Functional
Safety
Type
Approved
www.tuv.com
ID 10000000000
10
