- Page 1 PSZKT5A v.1.0 PSZKT 13,8V/5A/7Ah Buffer, switch mode power supply unit. Edition: 1 from 25.05.2018 Supersedes edition: -------------...
- Page 2 PSZKT5A Features: DC 13,8V uninterruptible power supply LED indication 75W power supply for ZKT access control cards protections: fitting battery: 7Ah/12V SCP short-circuit protection wide range of mains supply: 176÷264V OVP overvoltage protection ...
- Page 3 PSZKT5A 1.2 Block diagram Fig.1 Fig.1. The block diagram of the PSU. 1.3 Description of PSU components and connectors ( tab.1, tab.2, fig.2). Part no. Description [Fig. 2] PSU module green LED indicates AC power P1 potentiometer, output voltage adjustment...
- Page 4 PSZKT5A Fig.2. The view of the PSU. 1.4 Technical parameters: - electrical parameters (tab.3) - mechanical parameters (tab.4) - operation safety (tab.5) - operation parameters (tab.6) Electrical parameters (tab. 3) PSU type A (EPS - External Power Source) AC 176÷264V/50Hz...
- Page 5 PSZKT5A Mechanical parameters (tab. 4) Dimensions W=335, H=280, D+D =82+8 [+/- 2mm] =340, H =285 [+/- 2mm] Fixation See figure 2 Fitting battery 7Ah/12V (SLA) max. 165x100x75mm (WxHxD) max Net/gross weight 3,00 / 3,20 kg Enclosure Steel plate DC01, thickness: 1mm, colour: RAL 9005 (black)
- Page 6 PSZKT5A Chart 1. Acceptable output current from the PSU depending on ambient temperature. 2. Installation. 2.1 Requirements. The buffer PSU shall be mounted by a qualified installer with appropriate permissions and qualifications for 230V/AC installations and low-voltage installations (required and necessary for a given country). The device shall be mounted in confined spaces, according to the environment class II, with normal air humidity (RH=90% max.
- Page 7 PSZKT5A 3. Operating status indication. 3.1 LED indication of operating status. The is equipped with two diodes on the front panel: RED LED: on – the PSU is supplied with 230V AC off – no 230V AC supply GREEN LED: ...
- Page 8 PSZKT5A WEEE LABEL Waste electrical and electronic equipment must not be disposed of with normal household waste. According to the European Union WEEE Directive, waste electrical and electronic equipment should be disposed of separately from normal household waste. CAUTION! The power supply unit is adapted for cooperation with the sealed lead-acid batteries (SLA). After the operation period they must not be thrown but recycled according to the applicable law.
