AT45xx User's Guide
8
This chapter provides the following information:

2.1 Introduction

Thank you for purchasing AT45xx Multi-channel Temperature Meter
The Applent AT45xx adopts high-performance ARM microprocessor control, collects multi-channel temperature data
simultaneously. The AT45xx can be extended to 128 channels, compatible with a variety of temperature sensors, fast response,
data stability while with the burnout detection function. Also you can separately calibrate the data of each channel.
Configuration USB (virtual serial port) interface, through the software to achieve data acquisition, analysis and printing.
AT45xx Supports USB disk storage and save the sampling data real-time.

2.2 Main Specifications


Graduation: thermocouple J ,K, T, E, S, N, B,R

Measurement Range: -200.0℃~1800.0℃（change according to different thermocouple type）

Resolution: 0.1℃

Channel: 8 channels (can be extended to 128 channels)

Sample Rate: slow, med, fast

2.3 Main Functions

2.3.1

Functions

Comparator Setting
1.
2. Beep Setting
3. Baud Rate Setting
4. Temperature Unit Setting

2.3.2 Sorting Setting

Build-in sorting data, each temperature data can be set both up limit and low limit

2.3.3 Correction Function

Each channel data can been corrected by the user.

2.3.4 FAT Save Function

Users are allowed to create file suffix [.csv], every channel data can be saved in USB memory (do not support removable hard
disk)

2.3.5 System Setting

1. Keypad Lock Function
2. Switch both in English and Chinese
3. Date and Time Setting
4. Administrator and user accounts, password is available to the administrator

2.3.6 Remote Control

Support Max 115200bps baud rate, compatible with SCPI protocol, ASCII transfer

