Cequent Rola 59504 Manual

Please read all instructions carefully before assembly, installation and/or use of this product.
WARNING: The Maximum basket content weight capacity is 130 pounds (60 Kg).
DO NOT EXCEED the lowest of vehicle manufacturer's cross bar rating or basket content weight limit
of 130 pounds (60 Kg).
WARNING: Not for transport of people, animals, or flammable liquids.
WARNING: Distribute your load evenly inside the basket.
WARNING: Securely fasten load to cargo carrier. Make sure all bolts, screws, straps and plastic knobs are firmly
attached before every trip and check regularly during the trip.
WARNING: Check security of all cargo carrier attachments and load at fuel and rest stops.
WARNING: Check for clearance between sunroof and cargo carrier before operating sunroof. (if equipped)
WARNING: Do not carry any loads wider than your vehicle.
WARNING: Do not drill or weld to this product.
Vehicle Manufacturer's cross bar rating
(B)
(G)
(H)
PART PART PART PART
A A A A Cargo Carrier Basket (One Half)
B B B B
Air Deflector
C C C C
Plastic Hand Knob
D D D D
Top Mounting Bracket
E E E E
Spacer Bushing
F F F F
U-Bolt
G G G G
Screw, #10-32 (Self Tapping)
H H H H
Rubber Washer
I I I I
Small Locator Tube
J J J J
Large Locator Tube
Cequent Consumer Products Inc
Solon, OH 44139 USA
Cequent Help Hotline: 1-800-234-6992
Product Name:
LOAD RATING LIMITS:
-
PARTS LIST:
(C)
(A)
(D)
DESCRIPTION DESCRIPTION DESCRIPTION DESCRIPTION
Roof Top Carrier
Product Code:
59504
Basket Weight (35 Lbs.)
(G)
(E)
(F)
QTY. QTY. QTY. QTY.
2
1
8
4
4
4
12
4
2
2
Page 1 www.rolaproducts.com
= Cargo Carrier
Weight Limit
(J)
(I) (I) (I) (I)
TOOLS REQUIRED:
Phillips Screwdriver
Tape Measure
59504N Rev C 8-27-07
