SERVICE MANUAL
EN
704426 (DGIPRO-505)
DV1 Spraygun
ATEX approved Digital Pressure Gauge
II 2 G X
IMPORTANT! DO NOT DESTROY
It is the Customer's responsibility to have all operators and service personnel read and understand
this manual.
Contact your local Carlisle Fluid Technologies representative for additional copies of this manual.
READ ALL INSTRUCTIONS BEFORE OPERATING THIS PRODUCT.
SB-E-9-223 R1.0
www.carlisleft.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Carlisle DeVilbiss DV1
Summary of Contents for Carlisle DeVilbiss DV1
- Page 1 IMPORTANT! DO NOT DESTROY It is the Customer's responsibility to have all operators and service personnel read and understand this manual. Contact your local Carlisle Fluid Technologies representative for additional copies of this manual. READ ALL INSTRUCTIONS BEFORE OPERATING THIS PRODUCT. SB-E-9-223 R1.0...
-
Page 2: Functional Description
FUNCTIONAL DESCRIPTION The DGIPRO-505 Digital Pressure Gauge is an intrinsically safe device, approved to ATEX regulations 2014/34/EU, protection level; II 2 G Ex ia IIC T4 Gb, suitable for use in zones 1 and 2. The gauge is either supplied as a retrofit kit to existing DV1 sprayguns, or factory installed. The gauge is powered by a long life battery and has a life expectancy of 2 years under normal shift working conditions (following a max. - Page 3 Providing all conditions of safe use / installation stated within the product manuals have been complied with and also installed in accordance with any applicable local codes of practice. Director of Sales (EMEA) D Smith Signed for and on behalf of Carlisle Fluid Technologies UK Ltd: 13/3/17 SB-E-9-223 R1.0...
- Page 4 In this part sheet, the words WARNING, CAUTION and NOTE are used to emphasise important safety information as follows: WARNING CAUTION NOTE Hazards or unsafe practices which could result in Hazards or unsafe practices which could result in Important installation, operation or maintenance severe personal injury, death or substantial minor personal injury, product or property information.
-
Page 5: Exploded View
EXPLODED VIEW T10 TORX 1 Nm [10 in-lbs] 11mm HEX 9 Nm [80 in-lbs] PARTS LIST REF. PART No. DESCRIPTION QTY. 704426 DIGITAL GAUGE ASSEMBLY GAUGE MODULE 704420 DIGITAL GAUGE SPREADER VALVE AIR VALVE STEM SPREADER VALVE PIN O RING VALVE BODY O RING 704421... - Page 6 CAUTION NOTE • The digital gauge is suitable for use with both waterbased and solvent based coating materials. • It is not designed for use with highly corrosive and/or abrasive materials. • To avoid premature degradation of parts, DeVilbiss recommends that the digital gauge is washed in neutral cleaning solution [pH 6 to 8].
-
Page 7: Start-Up Sequence
START-UP SEQUENCE Turn spreader valve (10) anti-clockwise until fully wound out. Turn the air flow valve (12) at the bottom clockwise until fully wound in. With the hose connected, turn on the air supply. Open the air flow valve (12) by turning anti-clockwise and trigger the spraygun (air only). The gauge will show a reading in 0.05 bar [0.7 psi] increments. -
Page 8: Warranty Policy
WARRANTY POLICY This product is covered by Carlisle Fluid Technologies’ materials and workmanship limited warranty. The use of any parts or accessories, from a source other than Carlisle Fluid Technologies, will void all warranties. Failure to reasonably follow any maintenance guidance provided, may invalidate any warranty.
