Robotis STEM LEVEL1 Manual page 6

CM-530
AX-12W
AX-12A
IR Sensor Array
IR Sensor
2. 3. Operating
2. 3. 1. Download the Program
You can find task codes and motion files for other actions on the Standard,
How to download Task Code to controller
2. 3. 2. Turning the Robot on
1. Turn the power switch on and the LED will start blinking.
2. Use the MODE button to move the LED to "PLAY". (The LED will move each time you press
the MODE button)
3. Press the START button. (Check whether the LED on "PLAY" is blinking)
If the LED does not turn on, check the power cable/connection.
If there are no problems with cable, recharge your battery. (Please refer to Charging for
more information)
2. 3. 2. 1. The power does not turn on.
1. Is the battery properly connected?
2. Is the battery fully charged?
3. Is the battery fuse intact?
Please refer
2. 3. 2. 2. I want to check how much battery I have left.
Turn the CM-530 on and press the U button. The LED will turn on to show how much battery
you have left as seen in the figure below.
Fuse Replacement for information on how to replace the fuse.
Expansion page.
