p40 Squiggles Stander - User Manual
SQUIGGLES STANDER DIMENSIONS
Dimensions
Ages (approx)
Max User Weight
User Height
Chest Support Height
(Distance from footplate to armpit)
Chest/Hip Width
Hip Support Height
(Distance from footplate to mid-buttock)
Distance between mid line of knees
Footplate
Mobile Chassis Weights
Mobile Chassis Footprint
1 - 5
22.5kg 50lbs
Min 730mm / 28.5 inches
Max 1100mm / 43.3 inches
Min 160mm / 6.25 inches
Max 820mm / 9 inches
Min 160mm / 6.25 inches
Max 230mm / 20.8 inches
Min 300mm / 11.8 inches
Max 530mm / 20.8 inches
Min 140mm / 5.5 inches
Max 215mm / 8.4 inches
Plantarflexion 10º
Dorsiflexion 10º
Without suspension
and wheels 6.1kg
With suspension without
wheels 8.4kg
With suspension
and wheels 13.4kg
With Wheels
740mm x 740mm
Without Wheels
490mm x 760mm
