9.9 INSERTING
ATTACHMENT BOLT
INTO THE SANDALS
Insert the required attachment bolt
along with the retention plate
a rubber lid on, both, the top and
C
bottom of the sandal. Fasten using the
four screws provided. To remove or
replace the attachment bolt, reverse this
process.
. Place
C
Squiggles Stander - User Manual
9.10 ATTACHING
THE SANDALS
Place the sandal so that the attachment
bolt goes through the slot in the
footplate. To secure, on the underside of
the footplate place the rubber washer
, followed by the metal washer
then the knob C
bolt. To position the sandals simply
loosen the knob
select the position you require and
re-fasten the knob.
C
onto the attachment
C under the footplate,
p15
and
