  • Page 1 User Manual...
  • Page 2 Squiggles + Stander User Manual The Squiggles + Stander has been designed to offer the support your child needs in an upright, forward leaning (prone) or rearward leaning (supine) standing posture. The stander is modular in design and which have been developed for use in school or at home.

  • Page 3: Table Of Contents

    The maximum user weight regardless of which chassis is used is 22kgs (48.4lbs). 2.0 Declaration of Conformity Declaration of Conformity James Leckey Design Ltd. as manufacturer with sole responsibility declares that the Squiggles+ Standing System conforms to the requirements of the 93/42/EEC Guidelines Medical Device Regulations 2002 and EN12182 Technical aids for disabled persons.

  • Page 4: Terms Of Warranty

    Leckey manufactured products and components. 4.0 Product History Record Your Leckey product is classified as a Class 1 Medical device and as such should only be prescribed, set up or reissued for use by a technically competent person who has been trained in the use of this product.

  • Page 5: Safety Information

    Leckey equipment. important when the the push handle when support frame is in a moving the stander. 6.3 Only use Leckey reclined position. approved components with 6.12 The product contains your product. Never modify 6.8 When the product is in components which could the product in any way.

  • Page 6: How To Unpack And Assemble The Standing System

    Squiggles + Stander User Manual 6.0 Safety 6.16 The product is 6.17 Please be aware of a designed for indoor use and gap on the underside of the when not in use should be tray where a child could stored in a dry place that is insert their finger between not subjected to extremes the metal bracket and the...
  • Page 7 Squiggles + Stander User Manual The Squiggles + Stander can be used as a prone, supine or upright stander and has been designed to fit with a pivot chassis. 7.2 Attaching stander to pivot chassis To attach the stander to the Pivot Chassis, pull the locking pin out , slide...
  • Page 8 Squiggles + Stander User Manual 7.3 Attaching the headrest To attach the Leckey headrest first open the locking lever by pressing the safety button and pulling the handle Then slide the stem into the receiving bracket on the central spine, set to...
  • Page 9 Squiggles + Stander User Manual 7.5 Attaching the sandals Place the sandal so that the attachment bolt goes through the slot in the footplate. To secure, on the underside of the footplate place the rubber washer , followed by the metal washer and then the knob onto the attachment...
  • Page 10 p.10 Squiggles + Stander User Manual 7.7 Attaching the tray in prone and supine The tray is attached to the stander by inserting the tubes into the receiving brackets. Once the tray is located in position the knobs should be tightened. The cut out of the tray should always be facing the child.

  • Page 11: Fitting The Cushions

    Squiggles + Stander User Manual p.11 8.0 Fitting the Cushions 8.1 Hip cushions Place the cushion centrally on the chest/hip support plate . Feed the upper tab, which has the Velcro attached, over the top of the moulding and Velcro in place.
  • Page 12 p.12 Squiggles + Stander User Manual 8.3 Chest support harness The Chest support can be attached by clipping the male buckle into the female buckle at either side of the lateral supports. 8.4 Pelvic harness To attach the pelvic harness, simply slide the left and right sides of the harness over the lateral supports.
  • Page 13 Squiggles + Stander User Manual p.13 8.6 Knee support pads Open the knee supports fully. Insert child’s knee into place . Wrap small strap over the knee, then bring the longer wrap over to ensure a snug fit over the knee .
  • Page 14 The clinical setup of the product should be completed by a technically and clinically competent person who has been trained in the use of the product. Leckey recommend a written record is maintained of all clinical set-ups for this product.

  • Page 15: Clinical Setup For Postural Management

    Squiggles + Stander User Manual p.15 9.0 Clinical setup for postural management 9.1 Setting the Height Never attempt to adjust the Set the height first by height of the main frame when placing the child in a lying the stander is in use. position on a mat.
  • Page 16 p.16 Squiggles + Stander User Manual 9.3 Adjusting the push handle To prevent finger nipping always hold the push handle with one hand whilst making the adjustment with your other hand. The push handle height can be adjusted by loosening the Allen bolt at the attachment point to the...
  • Page 17 Squiggles + Stander User Manual p.17 9.5 Lateral supports Loosen the hand knob to adjust the width of the lateral supports and re-tighten when you have achieved the desired position. If, the lateral supports are attached with bolts instead of hand knobs they can be adjusted with the multi tool.
  • Page 18 p.18 Squiggles + Stander User Manual 9.8 Adjusting the sternum pad The sternum pad can be raised to provide additional support to assist thoracic extension. This also allows the chest support to be set lower to enable greater freedom of arm movement. The sternum plate is adjusted by loosening the two bolts at the front of...
  • Page 19 Squiggles + Stander User Manual p.19 9.10 Headrest adjustment The headrest should only be used when the child is in supine standing. To adjust the height, depth and angle of the contoured headrest, loosen the hand knobs and when set to the desired position re-tighten the knobs.
  • Page 20 p.20 Squiggles + Stander User Manual 9.12 Sandals positioning To position the sandals simply loosen the knob under the footplate, select the position you require and re-fasten the knob. To position the user’s feet in the sandals secure the Velcro straps provided so the foot is held in place.
  • Page 21 Squiggles + Stander User Manual p.21 9.14 Adjusting for abduction Loosen levers on each leg support. Adjust leg support to desired angle as displayed on the angle indicator. Re-tighten levers. 9.15 Product conversion – supine to prone To convert the Squiggles+ Supine Stander to accommodate prone standing, simply remove the...
  • Page 22 p.22 Squiggles + Stander User Manual 9.17 Adjusting the height of the tray in prone and supine The height adjustment knobs for the tray are located on either side of the central spine. Loosen the 2 knobs , select the required height and re-tighten.

  • Page 23: Frequent Adjustments For Daily Use

    6 by a technically and clinically competent person who has been trained in the use of the product. Leckey recommend that a written record is maintained of all parent and carers who have been trained in the use of this product.
  • Page 24 p.24 Squiggles + Stander User Manual 10.2 Chest and hip support harness To open the chest or hip support harness unclip one buckle and move the harness to one side leaving the other buckle attached. Reverse the process when placing the user back in the product.
  • Page 25 Squiggles + Stander User Manual p.25 10.4 Adjusting the height of the tray in prone and supine The height adjustment knobs for the tray are located on either side of the central spine. Loosen the 2 knobs , select the required height and re-tighten.
  • Page 26 p.26 Squiggles + Stander User Manual 10.7 Grab rail adjustment To set the depth of the grab rail to suit the child’s reach loosening knob adjust to the required depth and then re-tighten. To set the height of the rail, loosen knob slide the rail to the required height and...

  • Page 27: Cleaning & Care Information

    Squiggles + Stander User Manual p.27 11.0 Cleaning & Care Information How to Maintain When cleaning we recommend that you use only warm water and a non-abrasive detergent. Never use organic solvents or dry cleaning fluids. Upholstery and fabrics 1. The upholstery and fabrics can be cleaned by hand whilst in place.

  • Page 28: Daily Product Inspection

    4. Check all Velcro strips and brush fluff to ensure straps secure firmly. If in any doubt to the continued safe use of your Leckey product or if any parts should fail, please cease using the product and contact our Customer Care Team or your local...

  • Page 29: Annual Product Inspection

    If in any doubt to the continued safe use of your Leckey product or if any parts should fail, please cease using the product and contact our Customer Care Team or your local dealer as soon as possible.

  • Page 30: Reissuing Leckey Products

    If in any doubt to the continued safe use of your Leckey product or if any parts should fail, please cease using the product and contact our Customer Care Team or your local dealer as soon as possible.

  • Page 31: Technical Information

    Squiggles + Stander User Manual p.31 16.0 Technical Information Product and Accessory Codes 184-600 Stander support 184-764 Pivot Chassis 184-1800-02 Stander covers – Blue 184-1800-04 Stander covers – Purple 184-1800-09 Stander covers – Red 184-1800-09VIN Stander covers – Red Vinyl Accessories Codes prefixed by an asterix are available in four colour options.
  • Page 32 Leckey 19C Ballinderry Road Lisburn BT28 2SA Northern Ireland United Kingdom T: 028 9260 0750 F: 028 9260 0799 E: info@leckey.com W: www.leckey.com LS825-01...
