- Page 1 ATTE N TI O N: PLEASE FOLLOW THESE INSTRUCTIONS CAREFULLY. SEQUEL ®...
- Page 3 Thanks for purchasing the Sequel System. Before you begin setting up the Sequel System Components, it is imperative that you read the Consumer Considerations section on the next page.
- Page 4 Plan your space. Forethought is essential in determining the placement of each component. Using a measuring tape, determine how much space each unit will require. A cardboard template has been provided in order to help aid this process. Get someone to help you. Help from a second person is required for majority of the steps outlined in this instruction manual.
- Page 5 Power & Placement This page outlines two scenarios: Scenario 1 If cabinet is not blocking an AC power outlet, it may be positioned close to the wall. Power Top View Scenario 2 If cabinet is going to block an AC power outlet, position cabinet approximately 3”...
- Page 6 SEQUEL 6019 Corner Desk is engineered for easy assembly. Carefully follow this procedure to prevent any damage. Component List For missing hardware pieces, please contact BDI Customer Service at customerservice@bdiusa.com. For missing hardware pieces, please contact BDI Customer Service at customerservice@bdiusa.com.
- Page 7 Plan View Template Position the Template (G) in the desired location where the corner desk will be positioned, followed by the Sequel cabinets. Align the side of the cabinet with the outside edge of the template. NOTE: Cabinets’ top glass are not installed. Room View...
- Page 8 C x 4 Attach Leg to Desk Frame While the second person holds the desk frame on its side position, attach Corner Leg (J) to the underside of Desk Frame Assembly (H) using the Hex Wrench (A) and Machine Screws (C).
- Page 9 D x 4 Attach Desk Frame to Cabinets With the help of another person, carefully lower Desk Frame Assembly (H) onto the adjacent cabinets (Sequel Models 6014, 6015, 6016, or 6017). Adjust frame so that the holes are aligned with the threaded inserts on top of the cabinets.
- Page 10 E x 3 Bumpers, Drawer Liner & Template Install Rubber Stem Bumpers (E). With the grippy side facing down insert Drawer Liner (N) into the drawer. At this time, the cardboard template may be removed.
- Page 11 Wire Management (Optional) For the purpose of wire management, install Velcro Straps (M) to outside perimeter of Desk Frame Assembly (H).
- Page 12 F x 6 Install Glass With the help of another person, carefully lower the Glass Top (K) onto the frame. Register the steel discs on underside of glass into the holes on the frame; then attach the glass using Machine Screws (F) and Allen Wrench (A).
- Page 13 Install Glass Carefully lower the glass panel onto the Sequel Cabinet (Refer to individual instructions).
- Page 14 Magnets Located inside the Corner Leg (I) are 4 magnets that may be peeled and adhered to the rear side of a power strip. Leveler If needed, adjust leveler on Corner Leg using 3mm Hex Wrench (B).
- Page 15 Corner Leg Cover Upon completion of wire management, magnetically attach the Corner Leg Cover (J) to the front of the Corner Leg (I).
- Page 16 Designed by Matthew Weatherly. These distinctive product configurations are protected by US and international patents, trade dress, and/or copyright laws. “Sequel” and BDI are trademarks of Becker Designed, Inc. All Rights reserved. ©2011, BDI Made in Taiwan . 6019REV011315v2...
