TCL TRF-460WEXDA+ Service Manual page 10

S/N
21 Refrigerated direct current fan
22 The freezer air duct plate
23 Sealing cover of cooling air passage cover
24 Upper hinge cover left
25 Upper left hinge
26 Door switch
27 Turnover beam box fixing seat
28 Refrigerator shade
29 LED Light
30 Cold bulkhead assembly
31 Upper hinge cover right
32 Upper hinge right
33 Left guide rail assembly for fruit and vegetable box
34 Right guide rail component of fruit and vegetable box
35 Refrigerated bulkhead assembly
36 Mid hinge left
37 Mid hinge
38 LED Light
39 Dome lamp shade
40 Fin evaporator assembly
Material description Amount
1
1
1
1
1
4
1
2
2
1
1
1
1
1
1
1
1
2
2
1
