■Please carefully read the operation instructions before powering on, and keep them safe.
■Product specifications subject to change without notice.
Two-door Household Refrigerator
Operating Instructions
P529SBN
P529SBS
P529SBW
TCL Home Appliances (Hefei) Co., Ltd.
Address: No. 10 Yunhu Road, Economic Development Zone,
Hefei City, Anhui Province,China
Advertisement
Table of Contents
Related Manuals for TCL P529SBN
Summary of Contents for TCL P529SBN
- Page 1 ■Please carefully read the operation instructions before powering on, and keep them safe. ■Product specifications subject to change without notice. Two-door Household Refrigerator Operating Instructions P529SBN P529SBS P529SBW TCL Home Appliances (Hefei) Co., Ltd. Address: No. 10 Yunhu Road, Economic Development Zone, Hefei City, Anhui Province,China...
-
Page 3: Table Of Contents
Contents Thank you for buying TCL refrigerator. We hereby express our thanks. Welcome to use TCL refrigerator. We will do our best to provide you with quality service. Safety instructions ------------------------------------------------------------------------ Safety information ---------------------------------------------------------------------- Safety information ----------------------------------------------------------------- Product introduction ----------------------------------------------------------------... -
Page 4: Safety Instructions
Safety instructions 1.Warning Warning : No barrier is allowed around the appliance or in the embedded structure in order to ensure the free ventilation. Warning : Never damage the refrigerating circuit. Warning : Never place liquid beverages or food contained in glass containers in the freezing chamber as the glass container may crack. - Page 5 Safety instructions 2. . Caution Cautions : The power supply of this product must be uniform with the power supply mentioned on the nameplate, and the standard independent 3-hole socket shall be used (above 10A, and reliably grounded). One socket must not be shared by more than one appliance;...
- Page 6 Do not place any hot items in the fridge as it may cause damage to the plastic or operation.
- Page 7 Recycling...
- Page 8 The LED Lamp is not user replaceable. Contact your service agent for more details.
-
Page 9: Product Introduction
Product introduction Refrigerator air duct Freezer chamber door Refrigerating chamber door Upper freezer glass shelf Refrigerator bottle holder Upper refrigerator glass shelf Freezer bottle holder Lower refrigerator glass shelf Lower freezer glass shelf Lower refrigerator drawer Lower freezer drawer The pictures are for reference only. Please refer to the object Warm prompt: Product specifications subject to change. -
Page 10: Handling And Placement
Handling and placement The refrigerator shall be placed in an environment which is dry, has good ventilation, far from direct sunshine and heat source. >30cm >10cm >10cm T he refrigerator shall be Never place the refrigerator Do not operate the refrigerator on the foam base it was shipped on. -
Page 11: Preparations Prior To Use
This refrigerating appliance is not intended to be used as a built-in appliance P529SBN P529SBS >L1+380 >W1+600 P529SBW Preparations prior to use 1.Remove all packing materials such as adhesive tape, plastic bags, etc., especially the foam base. 2.Use a warm wet cloth to clean both interior and exterior of the refrigerator, (neutral detergent can be added to warm water). -
Page 12: Operation Keys
Operation keys Operation and diagram of the electronic control board The above is the computer control board of the product... - Page 13 Operation keys Powered on for the first time When it is powered on for the first time, the refrigerator will start the intelligent mode and run at 5 °C for the refrigerator chamber and -18 °C for the freezer chamber. Child lock function In the unlocked state, enter the "child lock"...
- Page 14 Operation keys operation. Once entering “Power Freezing”, the refrigerator will automatically quit the power freezing function after it is under “Power Freezing” for 4 hours. Under “Power Freezing” state, the setting temperature for the freezer chamber is displayed by -32°C till quitting the function. U nder “ Power Freezing” state, when setting other functions, you may automatically quit the power freezing func .t i o n Under “Power Freezing”...
- Page 15 Operation keys Foods storage Refrigerating chamber (2℃~8℃) --The refrigerating chamber is mainly used for storing short-term foods, like milk, eggs and bottled drink . s --Vegetables, melons and fruits shall be put into the fruit and vegetable box to prevent water loss. --The cooked foods shall be put into the refrigerator after packaging with the preservative bags, to prevent power from increasing.
-
Page 16: Care And Maintenance
To remove, gently squeeze from both sides at the same time and make sure the clips are dislodged, and then slowly lift out. shelf Care and maintenance It is suggested to maintain the refrigerator once per month; --Unplug the power plug to prevent from electric shock; --Use wet cloth or neutral detergent (cleanser essence to wipe off the oil contamination and other dirt. -
Page 17: Failure Analysis
Failure analysis The following items shall be inspected before occurring failures which require maintenance: Failures:Refrigerator does not work,The refrigeration effect is poor Causes:1. Check the connection of power supply. 2. Check whether the refrigerator is exposed to direct sunlight or whether there is heat source nearby. 3. Check whether there is heat dissipation space around refrigerator. -
Page 18: Technical Parameter
Technical prameter Technical parameter Model P529SBS P529SBN P529SBW Climate type Electric shock resistance Star sign 505L 505L 505L Total Volume 324L 324L Fresh food compartment 324L 181L 181L Volume of Freezer 181L Volume of Two-star Section 220-240V〜/50Hz 220-240V〜/50Hz Power type 220-240V〜/50Hz... -
Page 19: Packing List
Packing list P529SBN P529SBS P529SBW Ice Tray Egg Tray... - Page 20 Safe recovery instructions Disposal Old appliances still have some surplus value. An environmentally friendly approach will ensure that valuable raw materials are recycled. The refrigerants used in your equipment and insulation materials require special handling procedures. Make sure there is no pipe damage on the back of the equipment before handling. Up-to-date information on the options for disposing of old equipment and packaging from old equipment can be obtained from the local municipal office.
- Page 22 TCL Electronics Australia Pty Ltd. ABN 83 111 032 896 Telephone: 1300 738 149 sales.au@tcl.com www.tcl.com/au...
- Page 23 Material number:8B110-001059 Edition:202106-A.1...
