- Page 1 Refrigerator Service Manual TRF-210 TCL Home Appliances (HeFei) Co., Ltd.
-
Page 2: Table Of Contents
Contents 1.Product introduction 2.Exploded View of Product Structure 3.Product operation rules 4.Refrigeration system and electrical control 5.Maintenance guide... -
Page 3: Product Introduction
1.Product introduction... - Page 4 Technical Parameters...
-
Page 5: Exploded View Of Product Structure
2.Exploded View of Product Structure... - Page 6 Detailed list of refrigerator accessories Description of the material Quantity Upper hinge cover Upper hinge Mid hinge assembly Lower hinge assembly Adjustable feet Bracket Refrigerating middle bottle holder Refrigerating lower bottle holder Freezing glass shelf assembly Refrigerating glass shelf assembly Fruit and vegetable box glass shelf assembly Fruit and vegetable box Freezing chamber foam door body...
-
Page 7: Product Operation Rules
3.Product operation rules Temperature regulation --The temperature inside the refrigerator is controlled by the temperature controller mounted in the refrigerating chamber, which is provided with 8 gears (0, 1,2,..7).Temperature controller lighting combination panel-- The temperature inside the refrigerator decreases gradually when the temperature control knob is turned from 0 "7;... - Page 8 Food storage Refrigerating chamber (2 ° C ~ 8 ° C) --The refrigerating chamber is mainly used to store food for temporary preservation, such as milk, eggs and bottled beverages etc. --Vegetables, melon and fruits should be placed in the crisper to prevent water loss. --The cooked food should be packed with storage bags and placed in the refrigerator, so as to prevent back frosting and increase of energy consumption.
- Page 9 Defrosting is considered necessary when it is discovered that the freezer chamber evaporator is of thick frost layer. First of all, unplug the refrigeration power plug for power off, and then take out the drawer in the freezer chamber, and keep the refrigerator doors open. After the defrosting is completed automatically, wipe the moisture on the evaporator, door body and drawer with a clean and dry cloth, and place the drawer back to the freezer chamber, thus, defrosting is completed.
- Page 10 Accessory disassembly and assembly method --Refrigerating chamber glass shelf: it is able to store items with various volumes, and can be taken out by pulling gently upward and outward. --Crisper: it is used to store vegetables, fruits etc., and can be taken out by pulling outward.
-
Page 11: Refrigeration System And Electrical Control
4.Refrigeration system and electrical control (1) Schematic diagram of refrigeration Refrigerating evaporator Freezing evaporator Compressor Dew-proof tube Capillary tube Dry filter... - Page 12 (2) Pipeline welding drawing of pressing machine room Connection between the Connection between the compressor exhaust and the outlet of the dew removable inlet of the condenser tube and the dry filter Connection between the outlet of the condenser and the inlet of Dew-proof tube Intubation of process tube...
- Page 13 (3) Refrigerator circuit diagram...
-
Page 14: Maintenance Guide
5.Maintenance guide Before maintenance, it is necessary to know the actual usage of the user before taking corresponding measures User usage Guidance and handling Surrounding clearance: more than 10 cm at No clearance around the back and more than 30 cm at the top, keep it ventilated. - Page 15 The compressor does not work: Whether the refrigerating Whether the power plug is Whether the voltage is normal chamber light is on plugged in Make the voltage stable and normal Plug in the power plug Whether the compressor works Check whether the master Replace the master control board control board is normal Use a multimeter to test whether...
- Page 16 Excessive noise: Excessive noise Whether the ground is flat Keep the ground level Resonance with objects through collision Avoid collision with objects Whether the pipelines in the compressor Adjust the pipeline to avoid collision compartment collide with each other...
- Page 17 The compressor does not stop for a long time: The compressor does not stop for a long time Move it to a place with low ambient Whether the ambient temperature temperature is too high Whether the door of the Close the door of the refrigerator refrigerator is closed tightly tightly Whether the gear is appropriate...
- Page 18 The back of the refrigerating chamber is of thick frosting: The back of the refrigerating chamber is of thick frosting Whether the refrigerator is placed with the Reduce the moisture in the food food that are over-hydrated Remain certain distance between the food Whether the food is attached to the back and the back of the refrigerating chamber Whether the refrigerating door is...
