DESCRIPTION

KNOW YOUR STRING TRIMMER (Fig. 1)
The safe use of this product requires an understanding of the information on the tool and
in this operator's manual, as well as knowledge of the project you are attempting. Before
using this product, familiarize yourself with all operating features and safety rules.
1
Hinge (ST1520S/ST1510S/
ST1520S-FC/ST1510S-FC Only)
Hex Wrench
WARNING:
must always be on the tool to protect the user.
Adjustable Front-Assist Handle
Line-Loading
Button
Guard
Line-cutting Blade
Never operate the tool without the guard firmly in place. The guard
56-VOLT LITHIUM-ION CORDLESS 15" STRING TRIMMER
Lock-Off Button
Trimmer Head
(Bump Head)
Ejection Mechanism
Cutting Line
Release Tab
Rear Handle
Switch Trigger
Battery-Release Button
Electric Contacts
Latch
11
