Summary of Contents for Watson-Marlow Alitea 114 Series
-
Page 1: Table Of Contents
Good pump installation Flow rates and practice pressure capabilities 4.1 General recommendations 10 Tubing part numbers 4.2 Do’s and do not’s 11 Trademarks 4.3 Troubleshooting 12 Patient-connected use: warning 15 Pumphead mounting 13 Publication history Watson-Marlow Alitea 114 pumpheads: operating instructions... -
Page 2: Declaration Of Incorporation
Telephone +46 8 556 556 00. Fax +46 8 556 556 25. The information in this user guide is believed to be correct at the time of publica- tion. However, Watson-Marlow Alitea accepts no liability for errors or omissions. Watson-Marlow Alitea has a policy of continuous product improvement, and reserves the right to alter specifications without notice. -
Page 3: Safety Notes
If the product is used in a man- ner not specified by Watson-Marlow Ltd, the protection provided by the product may be impaired. -
Page 4: Product Specifications
114D—refer to 114DV; 114DP—refer to 114DVP. 114DV, 114DVP This product does not comply with the ATEX directive and must not be used in explosive atmospheres. 3.1 Dimensions 114 pumphead Unit weight 0.1kg Watson-Marlow Alitea 114 pumpheads: operating instructions... -
Page 5: Good Pump Installation
Users are advised to fit a pressure relief device between the pump and any valve on the discharge side of the pump to protect against damage caused by accidental operation with the discharge valve closed. Watson-Marlow Alitea 114 pumpheads: operating instructions... -
Page 6: Do's And Do Not's
Tube selection: The chemical compatibility lists published in Watson-Marlow pub- lications are guides. If in doubt about the compatibility of a tube material and the duty fluid, request a Watson-Marlow tube sample card for immersion trials. 4.3 Troubleshooting 114DV, 114DVP If the pump runs but there is little or no flow, make the following checks: Check that the tube is in the pumphead. -
Page 7: Pumphead Mounting
Allen-key headed M4 screws, length equal to 5mm + the thickness of the mount. Tighten them to a maximum of 0.5Nm. Drive shafts 8mm in diameter are recommended, but shafts from 6mm diameter to 10mm diameter are acceptable. Watson-Marlow Alitea 114 pumpheads: operating instructions... -
Page 8: Torque Requirement
Factors affecting torque requirement Bioprene More torque +Pressure occlusion Low temperature High temperature Standard occlusion Less torque Pumpsil Watson-Marlow Alitea 114 pumpheads: operating instructions... -
Page 9: Tube Holder Positioning
The inner setting will clamp the tube harder, reducing tube slip but has the potential to marginally reduce flow rate. The outer setting will optimise flow rate but the risk of tube slip is increased. Watson-Marlow Alitea 114 pumpheads: operating instructions... -
Page 10: Tube Holder Repositioning
Note: The pictures on the previous page show the tube holders’ correct positions for small and large tubing. If a tube holder is not vertical relative to the body of the pumphead, it is wrongly positioned. Follow the instructions above to reposition it. Watson-Marlow Alitea 114 pumpheads: operating instructions... -
Page 11: Tube Loading
The tube must not be twisted or stretched against the rollers. Lower the flip top until it clicks into its fully closed position. The track closes automatically and the tube is stretched correctly as it does so. Watson-Marlow Alitea 114 pumpheads: operating instructions... -
Page 12: Flow Rates And Pressure Capabilities
Reduce the flow rates quoted by 10% if using Pumpsil tubing. Recommended tubing 114DV: Bioprene, Marprene, Pumpsil, STA-PURE PCS and STA-PURE PFL 114DV (formerly CHEM-SURE). 114DVP: Bioprene, Marprene, Pumpsil, STA-PURE PCS, STA-PURE PFL 114DVP (formerly CHEM-SURE), PVC and Neoprene. Watson-Marlow Alitea 114 pumpheads: operating instructions... - Page 13 CW: Clockwise rotation optimizes the pump performance regarding tube life and required torque. Clockwise rotation is recommended for low or no pressure applica- tions. Suction performance and flow are the same as for CCW rotation. Watson-Marlow Alitea 114 pumpheads: operating instructions...
-
Page 14: Tubing Part Numbers
933.0032.016 913.A032.016 933.0040.016 902.0048.016 933.0048.016 913.A048.016 Tygon E3603* Neoprene* 920.0008.016 E3603.016.16 920.0016.016 E3603.032.16 920.0032.016 E3603.040.16 E3603.048.16 920.0048.016 STA-PURE PCS STA-PURE PFL 960.0016.016 965.0016.016 960.0032.016 965.0032.016 960.0048.016 965.0048.016 * Recommended for 114DVP +Pressure pumpheads only Watson-Marlow Alitea 114 pumpheads: operating instructions... -
Page 15: Trademarks
11 Trademarks 114DV, 114DVP Bioprene, LoadSure, Marprene, Pumpsil and Watson-Marlow are trademarks of Watson-Marlow Limited. Tygon is a trademark of Saint Gobain Corporation STA-PURE PFL and STA-PURE PCS are trademarks of W.L.Gore and Associates. 12 Warning not to use pumps in...
