    Quantum 600 Universal User Manual Contents 1 Declaration of conformity 2 Declaration of incorporation 3 Safety notes 4 Peristaltic pumps - an overview 5 When you unpack your pump 5.1 Unpacking your pump 5.2 Packaging disposal 5.3 Inspection 5.4 Components supplied 5.5 Storage...
  • Page 2 13 Mode menu 14 Manual 14.1 START 14.2 STOP 14.3 INCREASING AND DECREASING FLOW RATE 14.4 MAX FUNCTION (Manual mode only) 15 Flow calibration 15.1 Setting the flow calibration 16 Analog mode 16.1 Analog calibration 16.2 Calibrate Input 1 16.3 Setting a high signal 16.4 Setting high flow calibration 16.5 Setting a low signal 16.6 Setting low flow calibration...
  • Page 3 25 Troubleshooting 25.1 Error codes 25.2 Technical support 26 Drive maintenance 27 Drive spares 28 Ordering information 28.1 Pump part numbers 28.2 Cartridge part numbers 29 Warranty 30 Information for returning pumps 31 Name and address of manufacturer 32 Trademarks 33 Publication history 34 Disclaimers m-Quantum 600-gb-01...

  • Page 4: Declaration Of Conformity

    Declaration of conformity m-Quantum 600-gb-01...

  • Page 5: Declaration Of Incorporation

    Declaration of incorporation m-Quantum 600-gb-01...

  • Page 6: Safety Notes

    Safety notes This safety information should be used in conjunction with the rest of this operating manual. In the interests of safety, this pump and pumphead should only be used by competent, suitably trained personnel after they have read and understood the manual and considered any hazard involved.
  • Page 7 Fundamental work with regard to lifting, transportation, installation, starting-up, maintenance and repair should be performed by qualified personnel only. The unit must be isolated from mains power while work is being carried out. The motor must be secured against accidental start-up. Removal of the track and cartridge replacement should only be carried out by suitably trained personnel using the appropriate service tool.
  • Page 8 There are no user-serviceable fuses or parts inside this pump. ® Connect power using the supplied Harting PushPull Power cable. The mains plug at the opposite end of the cable is NOT IP66 rated. It is your responsibility to ensure that the connection to the mains supply is IP66 rated.
  • Page 9 Ensure the chemicals to be pumped are compatible with the pumphead, tubing, pipework and fittings to be used with the pump. Please refer to the chemical compatibility guide which can be found at: www.wmftg.com/chemical. If you need to use the pump with any other chemical please contact Watson-Marlow to confirm compatibility.

  • Page 10: Peristaltic Pumps - An Overview

    Peristaltic pumps - an overview Peristaltic pumps are the simplest possible pump, with no valves, seals or glands to clog or corrode. The fluid contacts only the bore of a tube, eliminating the risk of the pump contaminating the fluid, or the fluid contaminating the pump. How they work A compressible tube is squeezed between a roller and a track on an arc of a circle, creating a seal at the point of contact.

  • Page 11: When You Unpack Your Pump

    When you unpack your pump Unpacking your pump Unpack all parts carefully, retaining the packaging until you are sure all components are present and in good order. Check against the components supplied list, below. Packaging disposal Dispose of packaging materials safely, and in accordance with regulations in your area. The outer carton is made of wood and can be recycled.

  • Page 12: Main Parts Description

    Main Parts Description Track Pump Drive Unit Handles ReNu Single Use Cartridge Pumphead Rotor Power Isolation Switch m-Quantum 600-gb-01...

  • Page 13: Start-Up Check List

    Start-up check list Note: See also "Cartridge replacement" on page 70. Ensure that a single use cartridge is installed in the pumphead BEFORE the pump power is first turned on, (otherwise it is more difficult to set the operating language). Ensure that proper connections are achieved between the pump and suction and discharge piping.

  • Page 14: Bolt Down Bracket Installation

    Bolt Down Bracket Installation The supplied "Bolt Down Bracket" must be fitted to this pump in situations where the pumphead would be unsupported. An unsupported pumphead is likely to cause the pump unit to tip up and fall from its mounting location, which may cause damage or injury.

  • Page 15: Switching The Pump On For The First Time

    Switching the pump on for the first time Power up the pump. The pump displays Selecting the display the start-up screen with the Watson- language Marlow Pumps logo for three seconds. 1. Use the ∧/∨ keys to select your chosen language, and press SELECT.

  • Page 16: First-Time Start-Up Defaults

    First-time start-up defaults The pump is preset with operational parameters as shown in table below. Parameter Default setting Language Not set Default mode Manual Default manual speed 375rpm Pump status Stopped Max speed 400rpm Direction Cartridge ReNu SU 20/3P Tube material Flow calibration 53.33 ml/rev Flow units...
  • Page 17 The pump is now ready to operate according to the defaults listed above. Note: The display background colour changes according to running state as follows: White background indicates pump stopped Grey background indicates pump running Red background indicates error or alarm All operating parameters may be changed by means of key-presses (see section "Pump operation"...

  • Page 18: Switching The Pump On In Subsequent Power Cycles

    Switching the pump on in subsequent power cycles Subsequent power-up sequences will jump from the start-up screen to the home screen. The pump runs a power-on test to confirm proper functioning of the memory and hardware. If a fault is found, an error code is displayed. The pump displays the start-up screen with the Watson-Marlow Pumps logo for three seconds followed by the home screen Start-up defaults are those in place when the pump was last switched off...

  • Page 19: Pump Operation

    Pump operation 11.1 Keypad Layout and Key IDs HOME key When the HOME key is pressed it will return the user to the last known operating mode. If modifying pump settings when the HOME key is pressed, it will disregard any setting changes and return you to the last known operating mode.

  • Page 20: Starting And Stopping

    11.2 Starting and stopping Press key to start the pump. Press key to stop the pump. 11.3 Using up and down keys 11.4 Maximum speed Press key to start pump at maximum speed. m-Quantum 600-gb-01...

  • Page 21: Change Rotation Direction

    11.5 Change rotation direction m-Quantum 600-gb-01...

  • Page 22: Main Menu

    Main menu To access the main menu press the MENU button from one of the HOME screens or INFO screens. This will display the main menu as shown below. Use the ∧ /∨ keys to move the selection bar between the available options. Press SELECT to choose an option.

  • Page 23: Security Settings

    12.1 Security settings Security settings can be changed by selecting SECURITY SETTINGS from the Main menu. Auto keypad lock Press ENABLE/DISABLE to switch on/off the Auto keypad lock. When active the keypad will 'lock' after 20 seconds of inactivity. Once locked it will display the screen below when any key is pressed. To unlock the keypad press the two UNLOCK keys together.
  • Page 24 The padlock icon will appear on the operating mode home screen to show that keypad lock is activated. Note that the STOP key will always work whether the keypad is locked or not. PIN protection Using the ∧ /∨ keys select PIN protection from the SECURITY SETTINGS menu and press ENABLE/DISABLE to switch on/off the PIN protection.
  • Page 25 Setting Master PIN Setting the Master PIN protects all functionality. The Master is able to selectively enable functionality for two additional operators. These are defined as User 1 and User 2. They will be able to access this functionality by entering a PIN code assigned to them by the Master user.
  • Page 26 Now press CONFIRM to check that the number entered is the PIN you require. Press CHANGE to return to PIN entry. The following screen will be displayed to indicate that the Master PIN has been applied to access all functionality. Press NEXT to selectively enable functionality access for User 1 and User 2.
  • Page 27 Configure User 1 security settings The PIN PROTECTION level screen will be displayed with User 1 highlighted, press ENABLE to configure User 1 security settings or scroll to configure an alternative User. ENABLE user 1 security settings displays the PIN entry screen for User 1. To define a four digit User 1 PIN, use the ∧...
  • Page 28 Now press CONFIRM to verify that the number entered is the PIN you require. Press CHANGE to return to PIN entry. To define the allowed functionality, use the ∧ /∨ keys to select the functionality and press ENABLE. User 1 PIN will allow access to only the enabled functionality, to disable functionality, highlight the enabled functionality and press DISABLE.
  • Page 29 Configure User 2 security settings The PIN PROTECTION level screen will be displayed with User 2 highlighted, press ENABLE to configure User 2 security settings or scroll to configure an alternative User. ENABLE user 2 security settings displays the PIN entry screen for User 2. To define a four digit User 2 PIN, use the ∧...
  • Page 30 To define the allowed functionality, use the ∧ /∨ keys to select the functionality and press ENABLE. User 2 PIN will allow access to only the enabled functionality, to disable functionality, highlight the enabled functionality and press DISABLE. When all the required functionality has been enabled, press FINISH.
  • Page 31 If an incorrect PIN has been entered the following screen will be displayed. NOTE: this screen will also display if the PIN entered does not allow access to that functionality. If a PIN number is entered that is already in use, the following screen will be displayed, press CHANGE to input an alternative PIN or EXIT to abort m-Quantum 600-gb-01...
  • Page 32 If the PIN entered does not allow access to the functionality the following screen will be displayed. Keypad beep From SECURITY settings scroll to Keypad beep using the ∧ /∨ keys and select ENABLE. The pump will now beep at every key press. m-Quantum 600-gb-01...

  • Page 33: General Settings

    12.2 General settings To view the general settings menu, select GENERAL SETTINGS from the main menu. Auto restart This pump offers an auto restart feature. If active on power loss, it restores the pump when power returns to the operating state it was in when power was lost. For example, if the pump was running in analog mode prior to power loss, it would return to the same operating mode and continue to run at a proportional speed to the analog input.
  • Page 34 The ! icon is displayed on the home screens to indicate that the auto restart feature is active. Flow units The current chosen flow unit is displayed on the right hand side of the screen. To change flow units move the selection bar over the flow unit menu entry and press SELECT. Use the ∧...
  • Page 35 If a mass flow unit is selected, the specific gravity of the fluid must be entered. The following screen is displayed. Use the ∧ /∨ keys to enter the value of the specific gravity, and press SELECT. Pump label The pump label is a user defined 20 digit alphanumeric label which is displayed in the header bar of the home screen.
  • Page 36 Use the ∧ /∨ keys to scroll through the available characters for each digit. The available characters are 0-9, A-Z and SPACE. Press NEXT to move onto the next character, or PREVIOUS to move back to the previous character. Press FINISH to save the entry and return to the general settings menu. m-Quantum 600-gb-01...
  • Page 37 Pumphead information Use the ∧ /∨ keys to move the selection bar over Pumphead and press SELECT. The following screen will be displayed. Use the ∧ /∨ keys to move the selection bar over Pumphead and press SELECT. m-Quantum 600-gb-01...
  • Page 38 The PUMPHEAD MODEL screen allows the cartridge Lot Number to be recorded for future reference. Use the ∧ /∨ keys to move the selection bar over Cartridge lot number and press SELECT. Use the ∧ /∨ keys to scroll through the available characters for each digit. The available characters are 0-9, A-Z, and SPACE.
  • Page 39 Restore defaults To restore the factory default settings select Restore defaults from the general settings menu. There are two confirmation screens to ensure that this function is not carried out in error. Press CONFIRM followed by RE-CONFIRM to restore the defaults. Language Select language from the general settings menu to choose an alternative display language for the pump.

  • Page 40: Control Settings

    Press REJECT to return to the language choice screen. MODE menu Selecting MODE menu from the main menu will navigate you to access the sub- menu shown below. This is the same as pressing the MODE key. Please see "Mode menu" on page 46 for further details.
  • Page 41 Speed limit The maximum speed the pump is capable of running at is 400rpm. Select Speed limit from the control settings menu to define a lower maximum speed limit for the pump. This speed limit will be applied to all operating modes. Use the ∧...

  • Page 42: Configure Outputs

    Reset run hours Select Reset run hours from the control settings menu. Select RESET to zero the run hours counter. The run hours counter can be viewed by pressing INFO from your home screen. The following screen will be displayed. Press RESET to reset the run hours or CANCEL to return to the CONTROL SETTINGS menu.
  • Page 43 Use the ∧ /∨ keys and press SELECT to choose which pump status you require for the chosen output. The tick symbol indicates the current setting. Use the ∧ /∨ keys and press SELECT to choose the logic state of the chosen output. Press SELECT to program the output or BACKto cancel.

  • Page 44: Configure Inputs

    12.5 Configure inputs Select Configure inputs from the CONTROL SETTINGS menu. Use the ∧ /∨ keys and press SELECT to choose which input to configure. Use the ∧ /∨ keys and press SELECT to choose the logic state of the chosen output. Press SELECT to program the output or BACK to cancel.

  • Page 45: Help

    12.6 Help Select Help from the main menu to access the help screens. m-Quantum 600-gb-01...

  • Page 46: Mode Menu

    Mode menu Press MODE to display the Change mode menu. Use the ∧ and ∨ keys to scroll through the available modes: Manual (default) Flow calibration Analog Network MemoDose BACK m-Quantum 600-gb-01...
  • Page 47 Use SELECT to choose mode. Use the right hand function key to alter mode settings. m-Quantum 600-gb-01...

  • Page 48: Manual

    Manual All settings and functions of the pump in manual mode are set and controlled by means of key-presses. Immediately after the start-up display sequence detailed in: "Switching the pump on in subsequent power cycles" on page 18, the manual mode home screen will be displayed unless auto restart is enabled.

  • Page 49: Stop

    14.2 STOP Stops the pump. The display background changes to white. If the pump is not running pressing this has no effect. 14.3 INCREASING AND DECREASING FLOW RATE Using the ∧ and ∨ keys will increase or decrease the flow rate. m-Quantum 600-gb-01...

  • Page 50: Max Function (Manual Mode Only)

    Decreasing flow rate A single key press will decrease flow rate by the least significant digit of the chosen flow rate unit. Repeat key presses as required to achieve the desired flow rate. Hold down the key for flow rate scrolling. Increasing flow rate A single key press will increase flow rate by the least significant digit of the chosen flow rate unit.

  • Page 51: Flow Calibration

    Flow calibration This pump displays flow rate in ml/min. 15.1 Setting the flow calibration Using the ∧ /∨ keys, scroll to Flow calibration and press CALIBRATE. Using the ∧ /∨ keys, enter the maximum flow rate limit and press ENTER. m-Quantum 600-gb-01...
  • Page 52 Press START to begin pumping a volume of fluid for calibration. Press STOP to stop pumping fluid for the calibration. m-Quantum 600-gb-01...
  • Page 53 Use the ∧ /∨ keys to enter the actual volume of fluid pumped. To accept the new calibration press ACCEPT or RE-CALIBRATE to repeat the procedure. Press HOME or MODE to abort. The pump is now calibrated. m-Quantum 600-gb-01...

  • Page 54: Analog Mode

    Analog mode In this remote operating mode the flow rate will be proportional to the external milliamp or voltage signal input received by the pump. The relationship between the external analog signal and the flow rate is determined by configuring the two points A and B as shown in the graph below.

  • Page 55: Analog Calibration

    The analog signal being received by the pump is displayed, for information only, on the INFO screen. Press INFO to display this information. 16.1 Analog calibration The pump must be stopped before attempting to calibrate the values. High and low signals must be within range. If the signal sent is out of range you will not be able to set the signal input value and progress to the next step in the process.

  • Page 56: Calibrate Input

    16.2 Calibrate Input 1 Using the ∧ /∨ keys, scroll to Analog Input and press SELECT. Select the input signal type using the ∧ /∨ keys and press SELECT. The pump gives the option to enter the high and low mA or V signals manually or via the analog input.

  • Page 57: Setting A High Signal

    Choose whether to enter the current values manually via the keypad, or whether to apply the current signals electrically to the analog input. 16.3 Setting a high signal Send the high signal input to the pump, or enter the current value using the ∧ / ∨ keys. m-Quantum 600-gb-01...
  • Page 58 ACCEPT appears when high mA signal is within tolerance limits. Press ACCEPT to accept the high signal input or CANCEL to return to the previous screen. m-Quantum 600-gb-01...

  • Page 59: Setting High Flow Calibration

    16.4 Setting high flow calibration Using the ∧ / ∨ keys, scroll to the desired flow rate. Select SET FLOW or press BACK to return to the previous screen. 16.5 Setting a low signal Send the low signal input to the pump, or enter the current value using the ∧ / ∨ keys. m-Quantum 600-gb-01...
  • Page 60 If the range between the low and high signal is less than 1.5mA, the following error message will be displayed. ACCEPT appears when low mA signal is within tolerance limits. Press ACCEPT to accept the low signal input or CANCEL to return to the previous screen. m-Quantum 600-gb-01...

  • Page 61: Setting Low Flow Calibration

    16.6 Setting low flow calibration Using the ∧ / ∨ keys, scroll to the desired scale factor. Select SET FLOW. This proceeds to the screen confirming calibration is complete. Select ANALOG to start in analog mode or MANUAL to continue in manual mode. m-Quantum 600-gb-01...

  • Page 62: Memodose Mode

    MemoDose mode Each time the pump is started by pressing START, it records the number of pumphead revolutions which occur until STOP is pressed. The number of revolutions is proportional to the volume of fluid which has been dispensed: the dose. MemoDose mode allows the user to repeat-dose a precise volume of fluid.

  • Page 63: Set Flow Rate

    17.2 Set flow rate Using the ∧ /∨ keys, scroll to Flow rate and press SELECT. Using the ∧ /∨ keys, enter the dose flow rate and press SELECT. m-Quantum 600-gb-01...

  • Page 64: Resume Interrupted Doses

    17.3 Resume interrupted doses MemoDose Mode gives you the opportunity to resume interrupted doses following a power cycle (Note: Auto-restart must be on for this to function). Alternatively interrupted doses can be discarded and a new dose started when power is resumed. From the MemoDose settings screen, use the ∧...

  • Page 65: Master Dose

    If resume interrupted doses has NOT been set the following warning screen is displayed, press CONFIRM to save this setting. 17.4 Master dose Using the ∧ /∨ keys, scroll to Master dose and press SELECT. m-Quantum 600-gb-01...
  • Page 66 The following screen is displayed; press MANUAL to enter a dose via the keypad or DOSE to dispense a master dose. Dispensing a master dose Press START to begin dispensing the Master Dose. m-Quantum 600-gb-01...
  • Page 67 Press STOP to finish dispensing the Master Dose. Manual dose entry Press MANUAL on the master dose screen. Using the ∧ /∨ keys enter the required dose volume and press SELECT to record the master dose or CANCEL to return to MemoDose Settings.
  • Page 68 Save dose volume Press SAVE to record the Master Dose or CANCEL to return to MemoDose settings. When MemoDose SETTINGS are complete the following screen is displayed; press MEMODOSE to start in MemoDose Mode or BACK to return to MemoDose settings. m-Quantum 600-gb-01...

  • Page 69: Manual Dosing

    17.5 Manual dosing From the MemoDose Home screen, press START to deliver a dose. The screen displays the dose flow rate and the dose remaining counting down from 100% to 0%. If the delivered dose differs from the volume required, the percentage may be adjusted within the limits 1% to 999% of the master dose.

  • Page 70: Cartridge Replacement

    Cartridge replacement Removal of the track and cartridge replacement should only be carried out by suitably trained personnel using the appropriate service tool. Always isolate the pump from the mains power supply using the switch on the front of the unit (or other external means) before opening any track, or performing any positioning, removal or maintenance operation.
  • Page 71 The pump head with the Install the new cartridge over cartridge removed. the rotors. Lastly, close the Quantum Track Handles on the pumphead. Ensure the track is securely fitted and locked. Connector types ReNu SU 20/3P cartridge is fitted with 3/4" TriClamp connectors. m-Quantum 600-gb-01...

  • Page 72: Tube Replacement - Sanitary Connectors

    Tube Replacement - Sanitary Connectors Ensure that the pump is switched off. Take applicable precautions to catch any residual liquid that may be left in the tubes and cartridge. Follow the procedure below to install sanitary connectors, removal is a reverse procedure. 1.

  • Page 73: Good Pump Installation Practice

    Good pump installation practice 20.1 General recommendations It is recommended that the pump is sited on a flat, horizontal, rigid surface, free from excessive vibration, to ensure the correct pumphead operation. Allow a free flow of air around the pump to ensure that heat can be dissipated. Ensure that the ambient temperature around the pump does not exceed the recommended maximum operating temperature.
  • Page 74 Ensure that any unused M12 connectors are suitably sealed in order to maintain the IP/NEMA rating. Cartridge selection: The chemical compatibility guide published on the Watson Marlow website is for guidance. If in any doubt about the compatibility of a material and the duty fluid, contact Watson-Marlow.

  • Page 75: Connecting To A Power Supply

    Connecting to a power supply A well regulated electrical mains supply is required along with cable connections conforming to the best practice of noise immunity. It is not recommended to site these drives alongside 'dirty' electrical mains devices, such as 3-phase contactors and inductive heaters without special attention being paid to unacceptable mains-borne noise.

  • Page 76: Harting Connector

    21.1 Harting connector The pump is connected to the mains supply via a Harting connector plug on the rear of the pump, with connections as shown in the following diagram. Connect to IP66 standard by firmly pushing the plug until it is latched and then fix in place with the supplied clip.

  • Page 77: Control Wiring

    Control wiring 22.1 Quantum M12 interface power supply limits Signal Connector Voltage Load 5V Ref 4.5 - 5V @ no load Total of all pins 10mA max 10V Ref 10V @ no load Minimum load 4K7 ohms 22.2 Quantum universal interface M12 pin assignments The illustration below shows the M12 connectors as they appear on the rear panel, with their respective pinouts listed in the following table.

  • Page 78: Wiring The Inputs And Outputs

    Compatible, IP rated external shielded mating connector types: Amphenol, MSAS-08BFFB-SL7001, MSAS-08BMMB-SL7001. IP rated unshielded: Amphenol 12-08BMMA-SL8001, 12-08BFFA-SL8001. Shielded connections are recommended for minimising EMC emissions. The cable section must be circular to ensure a seal. Never apply mains power to the M12 terminals. Apply the correct signals to the terminals.
  • Page 79 Function Signal Response ANALOGUE 1 RUN/STOP DIRECTION m-Quantum 600-gb-01...
  • Page 80 Function Signal Response DIRECTION ENABLE TACHO F AUTO/MAN REMOTE POT. m-Quantum 600-gb-01...
  • Page 81 Function Signal Response DOSE LEAK DETECT TACHO RELAY 1 - 4 m-Quantum 600-gb-01...

  • Page 82: Pump Specifications

    Pump specifications 23.1 Specification ratings Operating temperature 5C to 30C (41F to 86F) -40C to 70C (-40F to 158F) Storage temperature Humidity (non- 80% up to 31C (88F) decreasing linearly to 50% at 40C condensing) (104F) Maximum altitude 2000m 650VA Power consumption Supply voltage Filtered 100-120V/200-240V 50/60Hz 1pH...

  • Page 83: Dimensions

    23.2 Dimensions All dimensions are in millimetres. m-Quantum 600-gb-01...

  • Page 84: Performance Data

    Performance data 24.1 Performance curves Flow rates of suction and discharge pressures for the pumphead at different drive speeds. This data was produced pumping water at ambient temperature. -0.5 Suction gauge pressure (bar) Discharge gauge pressure (bar) m-Quantum 600-gb-01...

  • Page 85: Troubleshooting

    Troubleshooting If the pump display remains blank when the pump is switched on, make the following checks: • Check that the mains power is available to the pump. • Check the fuse in the wall plug if one is present. •...

  • Page 86: Technical Support

    Error code Error condition Suggested action Stop pump immediately. Er10 Tacho fault Power OFF/ON may reset. Or seek support. Stop pump immediately. Er14 Speed error Power OFF/ON may reset. Or seek support. Stop pump immediately. Er15 Over current Power OFF/ON may reset. Or seek support. Stop pump immediately.

  • Page 87: Drive Maintenance

    Drive maintenance There are no user serviceable parts inside the pump. The unit should be returned to Watson-Marlow for service. m-Quantum 600-gb-01...

  • Page 88: Drive Spares

    Drive spares Description Part No. Quantum Main Fuse FS0067 Bolt Down Bracket QT0042T Quantum track assembly (with handles fitted) QTA0071A Quantum spallation tray QT0068M 14mm AF chrome vanadium combination spanner TT0018 IP Sealed CAP M12 CON1 MN2890B IP Sealed CAP M12 CON2, 3, 4 MN2889B Head Foot MN2507M...

  • Page 89: Ordering Information

    Ordering information 28.1 Pump part numbers • Plug options* U: UK mans plug E: EU mains plug A: American mains plug K: Australia mains plug R: Argentina mains plug C: Swiss mains plug D: India/South Africa mains plug 28.2 Cartridge part numbers Description Partcode ReNu SU 600 20/3P...

  • Page 90: Warranty

    Warranty Watson-Marlow Limited warrants this product to be free from defects in materials and workmanship for five years from the date of shipment, under normal use and service. Watson-Marlow Limited’s sole responsibility and the customer’s exclusive remedy for any claim arising out of the purchase of any product from Watson-Marlow Limited is, at Watson Marlow’s option: repair, replacement or credit, where applicable.
  • Page 91 Failure caused by UV light or direct sunlight. All ReNu pumpheads are excluded. Any attempt to disassemble a Watson-Marlow Limited product will invalidate the product warranty. Watson-Marlow Limited reserves the right to amend these terms and conditions at any time. Watson-Marlow reserves the right to amend these terms and conditions at any time.

  • Page 92: Information For Returning Pumps

    Information for returning pumps In compliance with the UK Health and Safety at Work Act and the Control of Substances Hazardous to Health Regulations, you are required to declare the substances which have been in contact with product (s) you return to Watson- Marlow or it subsidiaries or distributors.

  • Page 93: Trademarks

    Trademarks Watson-Marlow, Quantum and ReNu are trademarks of Watson-Marlow Limited. m-Quantum 600-gb-01...

  • Page 94: Publication History

    Publication history m-Quantum 600-gb-01 Quantum 600 Universal First published 01.17. m-Quantum 600-gb-01...

  • Page 95: Disclaimers

    Disclaimers The information contained in this document is believed to be correct but Watson-Marlow Fluid Technology Group accepts no liability for any errors it contains and reserves the right to alter specifications without notice. WARNING: This product is not designed for use in and should not be used for, patient- connected applications.
