Care and Maintenance of Aqua TROLL
Instruments
User Maintenance
Overview
It is important for users to perform scheduled
maintenance on their instruments to sustain the
accuracy and longevity of the probes and cables. The
frequency of this maintenance depends on the
characteristics of the deployment site, including
humidity levels and the degree of fouling.
Users should be aware of the conditions at their
deployment sites and develop appropriate maintenance
schedules to replace desiccant, clean the instruments,
and send in the instruments for factory calibration.
Users should check instruments often during the first
portion of the deployment to determine the frequency of
maintenance. General maintenance should be
performed as often as possible. Factory service should
be performed at least every 12 months.
Preventing Condensation
Desiccant
Desiccant protects electronics from condensation,
which can cause irreparable damage and loss of data.
Indicating desiccant changes from blue to pink as it
becomes saturated with moisture.
Desiccant stages (from left)
New, nearly expired (replace now), expired
Information subject to change without notice. In-Situ, In-Situ logo, Baro Merge, BaroTROLL, HERMIT, Pocket-Situ, RDO, RuggedCable,
RuggedReader, TROLL, and Win-Situ are trademarks or registered trademarks of In-Situ Inc. © 2012. All rights reserved.
Instruction Sheet
®
and Level TROLL
It is extremely important to use a properly-sized
desiccant for your deployment, and to change
desiccant often. Desiccant should be changed before
the entire volume has turned pink, and you should use
enough desiccant to effectively keep cables,
instruments and electrical boards dry until your next
scheduled maintenance. Desiccant life span is
dependent on site conditions.

Desiccant Pack Options

Small Desiccant
The Small Desiccant is a disposable cap that ships with
In-Situ Inc. products. The small desiccant is meant to
protect the instrument and cable only during
shipping, and should not be used for
deployments.
Large Desiccant (PN 0051810 and 0053550)
The Large Desiccant is a replaceable desiccant pack
designed for low-humidity environments or
deployments where maintenance occurs frequently.
The large desiccant is available with a plastic or a
titanium twist-lock connector.
®
08/2012 | Rev.001 |

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Aqua TROLL and is the answer not in the manual?

Questions and answers

Summary of Contents for In-situ Aqua TROLL

  • Page 1 New, nearly expired (replace now), expired Information subject to change without notice. In-Situ, In-Situ logo, Baro Merge, BaroTROLL, HERMIT, Pocket-Situ, RDO, RuggedCable, 08/2012 | Rev.001 | RuggedReader, TROLL, and Win-Situ are trademarks or registered trademarks of In-Situ Inc. © 2012. All rights reserved.
  • Page 2 Twist in opposite Remember, replace desiccant before it expires to directions to unlock the desiccant from the cable. prevent electronic damage to your instrument. 3. Attach the new desiccant pack to the twist-lock connector on the cable. 800-446-7488 www.in-situ.com...
  • Page 3 Acceptable cleaning processes for the Aqua TROLL Cleaning and Storage are listed below. Body and Front End of Probe Process 1: Light scrubbing with a soft swab and mild soap such as a dilute solution of dish detergent. Be Clean the instrument body with water and a soft brush...
  • Page 4 The copper TROLL Shield Nose Cone is designed to reduce macro- and micro-fouling of the pressure sensor TROLL Replaceable Battery Pack (PN on Level TROLL and Aqua TROLL Instruments. 0090000) Reduced fouling on the sensor improves measurement The TROLL Replaceable Battery Pack supplements accuracy and extends the length of deployments.
  • Page 5 In-House Factory Calibration reduce the fouling of the conductivity cell on Aqua TROLL 100 and 200 Instruments. Reduced fouling on Factory calibration of In-Situ Inc.instruments should be Instruction Sheet the sensor improves accuracy and extends the length of performed every 12 months, or when the unit data instrument deployments.
  • Page 6 European Union. For products under the requirement of WEEE directive, please contact your distributor or local In-Situ Inc. office for the proper decontamination information and take back program, which will facilitate the proper collection, treatment, recovery, recycling,...
