1
Install the sensors.
Twist the restrictor off the
probe.
Remove the orange plug
from the pH/ORP sensor
port.
1-970-498-1500
Aqua TROLL 400 Quickstart Guide
Required Components
1 Aqua TROLL 400 instrument
2 Wireless TROLL Com
3 Rugged Twist-Lock Cable
4 Bluetooth-enabled mobile device
Getting Started
Locate the RDO sensor
cap container and
remove the cap.
Use the alignment marks
to properly align the
pH/ORP sensor with the
port connection, and
press firmly into place.
Push until the sensor is
completely inserted into
the port.
Remove the dust cap
from the RDO sensor.
Twist the restrictor back
onto the probe.
5
Align the slotted edge of
the RDO cap with the flat
edge of the RDO sensor.
Press the cap firmly into
position.
2019-03-22 | 0090340
Advertisement
Table of Contents
Related Manuals for In-situ Aqua TROLL 400
Summary of Contents for In-situ Aqua TROLL 400
-
Page 1: Getting Started
Aqua TROLL 400 Quickstart Guide Required Components 1 Aqua TROLL 400 instrument 2 Wireless TROLL Com 3 Rugged Twist-Lock Cable 4 Bluetooth-enabled mobile device Getting Started Install the sensors. Twist the restrictor off the Locate the RDO sensor Remove the dust cap Align the slotted edge of probe. - Page 2 Wireless TROLL Com. serial number of Wireless TROLL COM. Select Choose or Add a Device. Tap mobile device's back Tap mobile device’s Back button to view button and tap serial number from list. Connected Instrument screen. 1-970-498-1500 www.in-situ.com...
- Page 3 VuSitu’s on-screen instructions will guide you through instrument calibration, livereadings, log setup and data sharing. Learn more. Get complete instructions about calibration, logging and working with data in the product manual. Download it from www.in-situ.com. 1-970-498-1500 www.in-situ.com...
