Operation
58
Parameter Endress+Hauser
Matrix (CW II)
Format display V6H4
No. decimals V6H5
Sep. character V6H6
Display test V6H7
Gap
Gap
Actual alarm V9H0
Last alarm V9H1
Clear last alarm V9H2
Reset V9H3
Operating code V9H4
Measured distance V9H5
Measured level V9H6
Gap
Application parameter V9H8
Gap
Tag no. VAH0
Profile revision VAH1
Version string VAH2
Gap
Serial no. VAH4
Distance unit VAH5
Gap
Download mode VAH8
Data strings
In der Slot/Index table some data types, e.g. DS-33 are marked by an asterisk. These are data strings
according to the PROFIBUS-PA specifications part 1, Version 3.0. They contain several elements,
which are addressed by an additional subindex. The following table gives an example.
Data type Subindex
1
DS-33
5
Levelflex M FMP40 PROFIBUS PA
Slot Index Size Type
[bytes]
1 202 1 UNSIGNED8
1 203 1 UNSIGNED8
1 204 1 UNSIGNED8
1 205 1 UNSIGNED8
1 206 - 207
1 218-227
1 228 STRUCT
1 229 STRUCT
1 230 1 UNSIGNED8
1 231 2 UNSIGNED16
1 232 2 UNSIGNED16
1 233 4 FLOAT
1 234 4 FLOAT
1 235
1 236 1 UNSIGNED8
1 237
1 238 STRING
1 239 STRING
1 240 STRING
1 241
1 242 STRING
1 243 2 UNSIGNED16
1 244 - 245
1 246 1 UNSIGNED8
Typ
FLOAT
UNSIGNED8
Read Write Storage
Class
x x static
x x static
x x static
x x static
x dynamic
x dynamic
x x static
x x static
x x static
x dynamic
x dynamic
x dynamic
x const
x x static
x const
x x static
x x static
x x static
Size [bytes]
4
1
