Levelflex M FMP40 PROFIBUS PA
Endress+Hauser
Parameter Endress+Hauser
Matrix (CW II)
In safety dist. V1H6
Reset self holding V1H7
Operating mode V1H8
Brocken probe det. V1H9
End of probe V2H0
Probe shortened V2H1
Probe free V2H2
Probe length V2H3
Probe length setup V2H4
Gap
Level/ullage V3H0
Linearisation mode V3H1
Customer unit V3H2
Table no. V3H3
Input level V3H4
Input volume V3H5
Max. volume V3H6
Cylinder vessel V3H7
Gap
Selection V4H0
check distance V4H1
Range of mapping V4H2
Mapping rec start V4H3
Pres. map. dist. V4H4
Delete mapping V4H5
Echo quality V4H6
Offset meas dist V4H7
Output damping V4H8
High blocking dist. V4H9
Bus address V5H0
Ident nr sel V5H1
Set unit to bus V5H2
AI out value V5H3
AI out status V5H4
Simulation type V5H5
Simulation value V5H6
2nd cyclic value V5H7
Select Main Value V5H8
Input value V5H9
Gap
Display contrast V6H1
Language V6H2
Back to home V6H3
Slot Index Size Type
[bytes]
1 154 1 UNSIGNED8
1 155 1 UNSIGNED8
1 156 1 UNSIGNED8
1 157 1 UNSIGNED8
1 158 1 UNSIGNED8
1 159 1 UNSIGNED8
1 160 1 UNSIGNED8
1 161 4 FLOAT
1 162 1 UNSIGNED8
1 163-167
1 168 1 UNSIGNED8
1 169 1 UNSIGNED8
1 170 1 UNSIGNED16
1 171 1 UNSIGNED8
1 172 4 FLOAT
1 173 4 FLOAT
1 174 4 FLOAT
1 175 4 FLOAT
1 176-177
1 178 1 UNSIGNED8
1 179 1 UNSIGNED8
1 180 4 FLOAT
1 181 1 UNSIGNED8
1 182 4 FLOAT
1 183 1 UNSIGNED8
1 184 1 UNSIGNED8
1 185 4 FLOAT
1 186 4 FLOAT
1 187 4 FLOAT
1 188 1 UNSIGNED8
1 189 1 UNSIGNED8
1 190 1 UNSIGNED8
1 191 4 FLOAT
1 192 1 UNSIGNED8
1 193 1 UNSIGNED8
1 194 4 FLOAT
1 195 1 UNSIGNED8
1 196 1 UNSIGNED8
1 197 4 FLOAT
1 198
1 199 1 UNSIGNED8
1 200 1 UNSIGNED8
1 201 2 INT16
Operation
Read Write Storage
Class
x x static
x x static
x x static
x x static
x x static
x x static
x x static
x x static
x x static
x x static
x x static
x x static
x x static
x x static
x x static
x x static
x x static
x x static
x x static
x x static
x x static
x dynamic
x x static
x dynamic
x x static
x x static
x x static
x dynamic
x x static
x x static
x dynamic
x dynamic
x x static
x x static
x x static
x x static
x dynamic
x x static
x x static
x x static
