Table 3-1. iQ Desktop+ Satellite Router Front Panel LED Descriptions (continued)
Label Signal Color/Type Definition
TX
NET
Installation, Support, and Maintenance Guide
iQ Desktop+ Satellite Router
Solid Green Downstream carrier configured, demodulator and NCR locked to
downstream carrier
Indicates the state of the transmitter
Solid Amber Transmitter is disabled
1 second flashing Transmitter acquiring upstream connection
Amber
Solid Green Transmitter upstream connection acquired
Modem Network Status: Indicates the state of the satellite
network connection
1 second flashing Network acquisition in progress
Green
Solid Green Network acquired
iQ Desktop+ Front Panel LED Status Descriptions
