VLT®AutomationDrive EZ FC 321
Installation Guide
Table 18: Recommended Maximum UL Fuse Class, Voltage Range 3x200–240 V, Enclosure Sizes A, B, and C
Class fuses
Power [hp] RK1/J/T [A]
0.34–0.5 5
0.75–1.5 10
2.0 15
3.0 20
4.0 25
5.0 30
7.5 50
10 60
15 80
20–25 125
30 150
40 200
50 250
Table 19: Recommended Maximum UL Fuse Class, Voltage Range 380–500 V, Enclosure Sizes A, B, and C
Class fuses
Power [hp] RK1/J/T [A]
0.5–1.5 6
2.0–3.0 10
4.0 15
5.0 20
7.5 25
10 30
15 40
20 50
25 60
30 80
40 100
50 125
60 150
75 200
100 250
Danfoss A/S © 2021.05
Semiconductor fuses
CC [A] SIBA Littelfuse
5 5017906-005 –
10 5017906-010 –
15 5017906-016 –
20 5017906-020 –
25 5017906-025 –
30 5012406-032 –
– 5014006-050 –
– 5014006-063 –
– 5014006-080 –
– 2028220-125 –
– 2028220-150 L25S-150
– 2028220-200 L25S-200
– 2028220-250 L25S-250
Semiconductor fuses
CC [A] SIBA Littelfuse
6 5017906-006 –
10 5017906-010 –
15 5017906-016 –
20 5017906-020 –
25 5017906-025 –
30 5012406-032 –
– 5014006-040 –
– 5014006-050 –
– 5014006-063 –
– 2028220-100 –
– 2028220-125 –
– 2028220-125 –
– 2028220-160 –
– 2028220-200 L50-S-225
– 2028220-250 L50-S-250
Ferraz Shawmut (Mersen)
–
–
–
–
–
–
–
–
–
–
A25X-150
A25X-200
A25X-250
Ferraz Shawmut (Mersen)
–
–
–
–
–
–
–
–
–
–
–
–
–
A50-P-225
A50-P-250
AN354546796134en-000201 / 130R0954 | 27
Electrical Installation
Bussmann (Eaton)
FWX-5
FWX-10
FWX-15
FWX-20
FWX-25
FWX-30
FWX-50
FWX-60
FWX-80
FWX-125
FWX-150
FWX-200
FWX-250
Bussmann (Eaton)
FWH-6
FWH-10
FWH-15
FWH-20
FWH-25
FWH-30
FWH-40
FWH-50
FWH-60
FWH-80
FWH-100
FWH-125
FWH-150
FWH-200
FWH-250
