Panduit FS148 Installation Instruction

© Panduit Corp. 2019
For your safety opera�on
The Lynx-CustomFit® Splice-On Connector is designed and
manufactured to assure personal safety. Improper opera�on
can result in bodily injury and serious damage to this product.
Please read and observe all warnings instruc�ons given in this
opera�on manual.
Wear safety glasses
!
handling op�cal fiber.
Never look into the end of a microscope or op�cal
!
cable connected to an op�cal output device that is
opera�ng. Laser radia�on is invisible, and direct
exposure can severely injure the human eye.
Alcohol is flammable, causes irrita�on and is harmful
!
if swallowed or inhaled. Keep alcohol away from
heat, sparks, skin, and avoid contact with eyes.
MPO Splice-On Connector for Bare Ribbon
Disposable
Holder (*1)
Front
Housing
w/Spring
Dust Cap
Polish Surface and Housing Color
SM Low Loss SM Std. Loss
8 degree Polish
Yellow Green
For Technical Support: www.panduit.com/resources/install_maintain.asp
MPO Splice-On Conector for Bare Ribbon and 3mm
Round Fiber Installation Instruction
INSTALLATION INSTRUCTIONS
to protect your eyes when
Composi�on
Rear Parts
Rear
Boot
Stopper
MT STUB
Dummy Cap
w/ Tether
(*1) 1 pc / 100 connectors
MM5010GOM3
Flat Polish
Aqua
1. Improper assembly will result in a loss of performance.
Please read instruc�ons
and the opera�on manual of the fusion splicer.
2. Never touch the fiber of the
in the factory.
3. The product is sensi�ve to dirt or dust. Do not take out
any parts from the package
4. The characteris�c will be influenced by the fiber
cleaved surface condi�on. Please use a cleaver which
has a good cleaving characteris�c.
5. Do not remove the dust cap
been completely assembled
high inser�on loss due to them.
Below equipment and tools are strongly recommended.
Fusion Splicer
Type-Q101-M12
(T-71M12)
Protec�on
Sleeve
Splicer
Type-Q101-M12
(T-71M12)
SMF : G.652, G.657
MMF : MM50(OM2), MM50(OM3), MM50(OM4)
Please perform Arc test prior to the splicing opera�on.
(See the opera�on manual of the splicer.)
*Ribbon fiber for tes�ng is included in the connector kit.
Please check fiber type inside the field fiber.
Page 1 of 5
Precau�ons
given in this opera�on manual
stub. It has been inspected
un�l it is to be
un�l the connector has
in order not to cause an
Assembling Tools
Jacket Fiber Holder
Fiber Cleaver
remover
FC-6RM etc.
JR-6
(For 12c Fiber)
Recommended Program
Fiber Splicing Program
SMF 12c SM12c
SMF 8c SM8c
MMF 12c MM12c
MMF 8c MM8c
FS148
used.
Fiber Holder
FHM-12 FHM-8
(For 8c Fiber)
Heater Program
Lynx MPO
