Panduit CM308F Install Instructions

© Panduit Corp. 2017
PART NUMBERS
Table 1
VERTICAL CABLE
MANAGEMENT
Front/Rear
WMPV22E
WMPV45E
WMPVHC45E WMPVHCF45E
NRV6
NRV10
NRV12
Location Guide for Center Mounting
(R2P with WMPVCBE and NRVCB)
Dimensions in () parenthesis are for 6" Vertical Cable Management

Standard Rack Installation

Bottom Mounting Location
FOR TECHNICAL SUPPORT www.panduit.com/resources/install_maintain.asp

Mounting Kits

(sold separately)
WMPVCBE, NRVCB
Front Only
(Center Mount)
WMPVF22E
(Standard mounting for
WMPVF45E Panduit 2 and 4 post racks
racks. One kit Included.)
WMPVSMK (Side Mount)
NRVF6
(Optional Mounting for
NRVF10
4 post racks and R2PS)
NRVF12
(Required Mounting for R2P6S)
2
Rear Bottom Mounting
#12-24 Screws
Location pin(s)
N R Vertical Cable Managers
ET UNNER
INSTRUCTIONS CM308F
Racks
R2P Series of Racks
R4P Series of Racks
ER4P Series of Racks
R2P Series of Racks
R4P Series of Racks

Bracket Installation

Note:
For additional brackets when
installing between two racks use
part number WMPVCBE or
NRVCB. Bracket is keyed to be
installed in the correct orientation.
Note:
Arrows and flags
must point upward
Location
3
Page 1 of 3
Doors
WMPV Includes
Cover
NRD6B1
NRD10B1
NRD12B1
1
4
Top Mounting Location
#12-24 Screws
