Preparation
To start squeezing you must follow the steps below:
Step 1 Unpack your juicer and place it on a surface as horizontal as possible.
Step 2 Ensure that the mains power falls within the margins indicated on the Iden-
tification Label of the machine which you will find both on the cover page of this
manual as well as on the machine itself.
Step 3 Place the peel buckets as indicated in Fig. 1 and 4.
Paso 4 Make sure that the juice container and its filter are placed correctly and that the
cover is closed and secured by the catch.
If you have acquired a juicer with a podium, you must place the juicer on the podium,
screw it as indicated in the instruction supplied on the podium. Don't forget to secure
the front wheels. Then place the hopper and the peel buckets with an open base
which you will find inside the stand (Fig. 2).
REMEMBER:
65 and 78 mm recommended)
Operation
Once the previous steps have been followed, connect the connecting plug to a socket
base fitted with a standardized ground. And press the sleeve button
the machine.
When you turn on the machine for the first time after purchase, a message will appear:
"Choose your language" in order to select the operating language of the machine.
The choice can be made using the arrows
machine will be ready for operation in "Self-Service" mode.
As a general rule, to operate within the menu, we can regard the "ON" button as
accept and "OFF" as cancel.
42 Usage Instructions
1_AF_Espanol_Ingles_Interior.indd 42
Use fruit which does not exceed 81 mm in diameter. (Between
English
and pressing "ON". Once selected, the
