Thermostat Z-Wave Specification
5.1.47 0x2F : RESERVED
5.1.48 0x30 : PIR Enable
• Default is enabled.
• Size 1 byte
5.1.49 0x31 : Display Options
• Bitmask to set display options.
o Bit 0 – if '1', show humidity on the main screen in all modes.
• Default is 0x00
• Size 1 byte
5.1.50 0x32 : System Configuration (READ ONLY)
• Summarized report of system configuration
Bits 7
Aux Fan
Loads Z2 Configuration
State
Reserved
Reserved
• HVAC Type : 00b – Normal, 01b – Heat Pump
• Fuel : 0b – Fuel, 1b -Electric
• Aux Fan : 0b- Disabled, 1b – Enabled
• Override : 1b – Relays manually configured, 0b – Relays automatically detected
• Size 4 bytes
5.1.51 0x33 : Thermostat Reset (Write Only)
• Must write the magic value 0x0B36 to take effect.
• Size 2 byte
5.1.52 0x34 : Vent Options
• 0x00 – Disabled
• 0x01 – Always activate regardless of thermostat operating state
• 0x02 – Only activate vent when the thermostat operating state is heating.
• 0x03 – Only activate vent when the thermostat operating state is cooling.
• 0x04 – Only activate the vent when the thermostat operating state is heating or cooling.
• Default is 0x04
• Size 1 byte
6 5 4
Cool Stages Heat Stages
Building 36 Technologies
An Alarm.com Company
3 2 1
Fuel HVAC Type
Z1 Configuration
June 26, 2019
0
Override
