Shelby - Cabin Bed
Assembly Instructions
Dimensions
Width - 195cm
Depth - 95.5cm
Height - 53cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
- Please keep for future reference
322/0296
338/9663
0345 6400800
Issue 1 - 9/02/10
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos Shelby 322/0296
Summary of Contents for Argos Shelby 322/0296
- Page 1 Shelby - Cabin Bed Assembly Instructions 322/0296 - Please keep for future reference 338/9663 Dimensions Width - 195cm Depth - 95.5cm Height - 53cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 0345 6400800 Issue 1 - 9/02/10...
-
Page 2: Handy Hints
Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • Do not stand or put weight on • To reduce components and tools listed on the product, this could cause the likelihood of pages 2, 3 and 4. - Page 3 Components - Panels If you have damaged or missing components, call the Customer Helpline: 0345 6400800 Please check you have all the panels listed below Left side panel Right side panel (95.5 x 53cm) (95.5 x 53cm) Front bed board (192 x 39.45cm) Back bed board (192 x 56.05cm)
- Page 4 Components - Panels If you have damaged or missing components, call the Customer Helpline: 0345 6400800 Please check you have all the panels listed below Middle crossbar Back crossbar (94 x 12cm) (94 x 10cm) Front crossbar (94 x 10cm) Left shelf partition Right shelf partition (94 x 37.2cm)
- Page 5 Components - Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. 50mm wood screw x 20 50mm fixing screw x 31 30mm wooden dowel x 14 Locking nut x 4...
- Page 6 Assembly Instructions Step 1 Attaching runners Position runners Front edge in from front edge of the left shelf partition runners 2mm in from front edge of the right shelf partition Fix through holes shown using 13mm fixing screws Insert the 30mm dowels into left shelf partition and into right shelf partition...
- Page 7 Assembly Instructions Step 3 Attaching panels Insert the 30mm dowels into left shelf Clockwise partition and into right shelf partition Position left central support to left bottom panel and right central support right bottom panel Fix the panels through 50mm fixing screw Note: Use the Allen Key Position the attached panels: left central...
- Page 8 Assembly Instructions Step 4 Attaching panels Insert the 30mm dowels into left side panel and into right side panel Position the left side panel and the right side panel like shown on the picture and fix them to left central support , left bottom panel...
- Page 9 Assembly Instructions Step 5 Attaching panel Screw plastic supports to the front board through 16mm wood screws First rotate the construction of the bed horizontally at 180 degrees and then vertically at 90 degrees like shown on the pictures. Position the front board and screw it to left central support...
- Page 10 Assembly Instructions Step 6 Attaching panels Two people are needed here Clockwise Position the front bed board and the back bed bord and fix them to left shelf partition and right shelf partition through 50mm fixing screws Note: Use the Allen Key Fix the left side panel and the right side panel...
- Page 11 Assembly Instructions Step 7 Attaching panels Two people are needed here Clockwise Position the front/ back bed supports and fix them to the front bed board and the back bed board through 50mm fixing screws Note: Use the Allen Key Fix the front/back bed supports to the...
- Page 12 Assembly Instructions Step 8 Attaching shelf Position the shelf supports into the right shelf partition and the right side panel Position the shelf its place like shown on the picture. Step 9 Assembling drawer Fold the drawer sides like shown on the picture.
- Page 13 Assembly Instructions Step 9 - continued Position the wooden dowels and the screw- in dowels . Position the drawer sides and the drawer bottom onto the front panel Insert the locking nuts into the drawer sides. Use a screwdriver to turn locking nuts clockwise to lock.
- Page 14 Assembly Instructions Step 10 Placing drawers Position the drawers into the bed like shown on the picture. Assembly is complete. 0345 6400800 If you need help or have damaged or missing parts, call the Customer Helpline: Domestic address or Home Retail Group Plc address.
