Manual AB38 BI-ENERGY SERIAL NO. 2767 to Current WARNING All personnel shall carefully read, understand and follow all safety rules, operating instructions, and National Safety Instructions/Requirements before operating or performing maintenance on any UpRight Aerial Work Platform. p/n : 502513-000...
Page 2
Serial Numbers 2767 – Current NGLISH When contacting UpRight for service or parts information, be sure to include the MODEL and SERIAL NUMBERS from the equipment nameplate. Should the nameplate be missing, the SERIAL NUMBER is also stamped on top of the chassis above the front axle pivot.
NEVER charge batteries near sparks or open flame. Charging batteries emit explosive hydrogen gas. Modifications to the aerial work platform are prohibited or permissible only at the approval by UpRight. AFTER USE, secure the work platform from unauthorized use by turning the keyswitch off and removing key.
Introduction NTRODUCTION This manual covers the AB38 Bi-Energy Aerial Work Platform. This manual must be stored on the machine at all times. Read, understand and follow all safety rules and operating instructions before attempting to operate the machine. ENERAL ESCRIPTION Figure 1: AB38 Bi-Energy 1.
V E R L O A D L A R M The AB38 Bi-Energy is fitted with a load sensing system designed to comply with the requirements os BS EN 280 : 2001 If a load equivelent to 90% of safe working load is lifted a fault code “03” will be displayed on the digital display on the platform control box.
Controls and Indicators ONTROLS AND NDICATORS The operator shall know the location of each control and indicator and have a thorough knowledge of the function and operation of each before attempting to operate the unit. Figure 2: Controls and Indicators Upper Controls 1.
System Function Inspection YSTEM UNCTION NSPECTION Refer to Figure 1 and Figur e2 for the locations of various controls and indicators. W A R N I N G STAND CLEAR of the work platform while performing the following checks. Before operating the machine, survey the work area for surface hazards such as holes, drop-offs, bumps and debris.
Operation O T A T I N G T H E L A T F O R M 1. Select the rotate function button (the button will illuminate to confirm selection). 2. While engaging the Interlock Switch, move the Control Handle forwards or backwards to achieve clock- wise or counterclockwise rotation.
Transporting the Machine RANSPORTING THE ACHINE R A N E Secure the straps to chassis lifting/tie down points only. O R K L I F T D A N G E R Forklifting and Lifting by Crane are for transport only. See specifications for weight of machine and be certain that forklift is of adequate capacity to lift the machine.
Maintenance AINTENANCE W A R N I N G Never perform service while the platform is elevated. Y D R A U L I C L U I D The hydraulic fluid reservoir is located in the chassis door. Figure 5: Hydraulic Fluid Reservoir and Dipstick NOTE: Never add fluid if the platform is elevated.
Battery fluid is highly corrosive. Thoroughly rinse away any spilled fluid with clean water. Always replace batteries with UpRight batteries or manufacturer approved replacements weighing 26,3 kg (58 lbs.) each. • Check the battery fluid level daily, especially if the machine is being used in a warm, dry climate.
Inspection and Maintenance Schedule NSPECTION AND AINTENANCE CHEDULE The Complete Inspection consists of periodic visual and operational checks, along with periodic minor adjustments that assure proper performance. Daily inspection will prevent abnormal wear and prolong the life of all systems. The inspection and maintenance schedule should be performed at the specified inter- vals.
Labels ABELS These labels shall be present and in good condition before operating the machine. Be sure to read, under- stand and follow these labels when operating the machine. Operation Manual Page 13...
Specifications PECIFICATIONS ITEM METRIC IMPERIAL Duty Cycle 45% of 8 hour s hift Platform Size 0.7 m x 1.3 m (ins ide guardrails ) Max. Platform Capacity 200 kg 440 lbs CE Version 215 kg 475 lbs ANSI Version Max. Num ber of Occupants 2 People 2 People Height...
Page 17
This section lists and illustrates the replaceable assemblies and parts of this product, as manufactured by UpRight. Each parts list contains the component parts for that assembly. ONTENTS General Assembly.............Page 2 & Page 3 Engine Spares................Page 4 Electrical Schematic..............Page 5 Alternator Schematic..............Page 6 AB38 Bi-Energy PARTS MANUAL Page1...
Page 19
Illustrated Parts Breakdown - General Assembly Drawing # AB38 Bi-Energy PARTS MANUAL Page3...
Page 20
Engine & Alternator Assembly Item Part Description QTY. 501743-000 ENGINE 501744-000 ALTERNATOR 501745-000 FUEL PUMP 501746-000 FUEL PIPE 501747-000 FUEL TANK 501754-000 KUBOTA OC95 SERVICE & PARTS MANUAL 501822-000 FUEL FILTER 11460-63012 STARTER 11460-03310 HEAD GASKET Page4 AB38 Bi-Energy PARTS MANUAL...
Page 21
Illustrated Parts Breakdown - Engine & Alternator Assembly AB38 Bi-Energy PARTS MANUAL Page5...
Page 22
Illustrated Parts Breakdown - Engine & Alternator Assembly Page6 AB38 Bi-Energy PARTS MANUAL...
Page 24
Local Distributor: UI Distribution North America inc. 2686 S. Maple Avenue Fresno, CA, 93725 Tel: (559) 443 6600 Fax: (559) 268 2433 Email: info@uidistribution.com www.uidistribution.com UROPE TEL: +353 1 620 9300 FAX: +353 1 620 9301 Unit S1, Park West Industrial Park Friel Avenue Nangor Road Dublin 12, Ireland...
