USE AND CARE GUIDE
Questions, problems, missing parts? Before returning to the store,
8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST Saturday
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this ceiling fan. We strive to
continually create quality products designed to enhance your home. Visit us online to see our full line of products available for
your home improvement needs. Thank you for choosing Hampton Bay!
METARIE II 24 IN. CEILING FAN
call Hampton Bay Customer Service
1-855-HD-HAMPTON
HAMPTONBAY.COM
Visual instruction of how to install this fan:
Visit www.homedepot.com and enter either the Item or Model number to find
this fan and click the link of visual instruction in the product overview section.
THANK YOU
Item #1005 710 278
1005 710 276
Model #YG922B-BN
YG922B-EB
Advertisement
Table of Contents
Related Manuals for HAMPTON BAY METARIE II 24
Summary of Contents for HAMPTON BAY METARIE II 24
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this ceiling fan. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for...
-
Page 2: Table Of Contents
Table of Contents Table of Contents ........Operation . -
Page 3: Safety Information
Safety Information To reduce the risk of electric shock, ensure electricity has been However, there is no guarantee that interference will not occur turned off at the circuit breaker or fuse box before beginning. in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be All wiring must be in accordance with the National Electrical determined by turning the equipment off and on, the user is... -
Page 4: Warranty
Warranty The manufacturer warrants the fan motor to be free from defects in workmanship and material present at time of shipment from the factory for a period of lifetime after the date of purchase by the original purchaser. The manufacturer warrants the light kit (excluding any glass), to be free from defects in workmanship and material at the time of shipment from the factory for a period of three years after the date of purchase by the original purchaser. -
Page 5: Hardware Included
Pre-Installation (continued) HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity Plastic wire nut Blade attachment screw Blade attachment nut Blade attachment lock washer 9 Watt LED bulb Pull chain and fob HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance. -
Page 6: Package Contents
Pre-Installation (continued) PACKAGE CONTENTS Part Description Quantity Part Description Quantity Mounting bracket (preassembled) Blade arm Canopy Blade Canopy bottom cover (preassembled) Switch housing Hanger ball/downrod assembly Light kit Fan motor assembly Plastic shade... -
Page 7: Installation
Installation MOUNTING OPTIONS NOTE: You may need a longer downrod to maintain proper WARNING: To reduce the risk of fire, electric shock, or blade clearance when installing on a steep, sloped ceiling. personal injury, mount the fan to an outlet box marked The maximum angle allowable is 18°... -
Page 8: Assembly
Assembly Preparing the canopy Preparing the motor Remove the canopy bottom cover (C) from the canopy (B) by Remove the cotter pin (HH) and clevis pin (II), and loosen the turning the canopy bottom cover (C) counterclockwise. two collar setscrews (JJ) from the motor collar. Remove the mounting bracket (A) from the canopy (B) by removing the non-slotted canopy mounting screws (GG) from the bottom of the canopy (B) and loosening the slotted... -
Page 9: Hanging The Fan
Assembly — Hanging the Fan Installing the mounting bracket Hanging the fan to the mounting to the electrical box bracket WARNING: To reduce the risk of fire, electric shock or WARNING: The tab in the ring must rest in the groove of other personal injury, mount the fan only to an outlet box or the hanger ball/downrod assembly (D). - Page 10 Assembly — Hanging the Fan (continued) Making the electrical connections WARNING: To avoid possible electrical shock, be sure Ground electricity is turned off at the main fuse box before wiring. conductor Neutral Black White WARNING: Check to see that all connections are tight, including ground, and that no bare wire is visible at the wire nuts (except for the ground wire).
- Page 11 Assembly — Hanging the Fan (optional) Single Switch Connections Dual Switch Connections On a single switch the fan and light can be turned on or off On a dual switch the fan and light can be turned on or off together.
- Page 12 Assembly — Hanging the Fan (continued) Installing the canopy Attaching the canopy bottom cover WARNING: Make sure the tab on the mounting bracket (A) NOTE: Adjust the canopy mounting screws (GG) as properly sits in the groove in the hanger ball (D) before necessary until the canopy (B) and canopy bottom cover (C) attaching the canopy (B) to the mounting bracket (A) by are snug.
-
Page 13: Attaching The Fan Blades
Assembly — Attaching the Fan Blades Attaching the blades to the blade Fastening the blade assemblies arms to the motor Attach the blades (G) to the blade arms (F) using the Blade WARNING: To reduce the risk of personal injury, do not screws (BB) , nuts (CC) , lock washers (DD). -
Page 14: Installing The Light Kit
Assembly — Installing the Light Kit Attaching the switch housing to Attaching the light kit to the the mounting ring switch housing Remove one of the four light kit mounting screws (OO) from CAUTION: Before starting installation, disconnect the the switch housing (H) and loosen the other three screws power by turning off the circuit breaker or removing the fuse (OO). - Page 15 Assembly — Installing the Light Kit (continued) Installing the light bulbs and plastic shade CAUTION: Before starting installation, disconnect the power by turning off the circuit breaker or removing the fuse at the fuse box. Turning power off using the fan switch is not sufficient to prevent electric shock.
-
Page 16: Operation
Operation PULL CHAIN OPERATING INSTRUCTIONS Install the pull chains and fobs (FF) onto the pull chains located in the switch housing (H). Turn on the power and check the operation of the fan. The pull chain controls the fan speed as follows: 1 pull - High, 2 pulls - Medium, 3 pulls - Low, and 4 pulls - Off. -
Page 17: Care And Cleaning
Care and Cleaning Do not Check the support connections, brackets, and blade Use water when cleaning. Water could damage the motor, attachments twice a year. Make sure they are secure. or the wood, or possibly cause an electrical shock. Because of the fan’s natural movement, some connections may become loose over time. - Page 18 Troubleshooting (continued) Problem Solution Verify that all blades and blade bracket screws are secure (most fan wobble problems are caused by loose parts). Once the fan is properly installed, run the ceiling fan for 10 minutes to let the fan self-adjust. If wobble occurs after running the fan for 10 minutes, verify blade level using the following process: - Select a point on the ceiling above the tip of one of the blades, then select any fan blade and measure from the center of the selected blade to the point on the ceiling.
-
Page 19: Service Parts
