    52” BeverleyII Thank you for purchasing our ceiling fan. This product has been manufactured with the highest standards of safety and quality. Ceiling Fan by Hampton Bay Date Purchased Table of Contents Store Purchased Safety Rules ....1 325-475 Model No.
  • Page 4: Safety Rules

    Safety Rules - Read and Save These Instructions To reduce the risk of electric shock, insure electricity has been turned off After making electrical connections, spliced conductors should be turned at the circuit breaker or fuse box before beginning. upward and pushed carefully up into outlet box. The wires should be spread apart with the grounded conductor and the equipment-grounding All wiring must be in accordance with the National Electrical Code conductor on one side of the outlet box and ungrounded conductor on the...
  • Page 5: Unpacking Your Fan

    Unpacking Your Fan Unpack your fan and check the contents. You should have the following items: Set of blades (5) Set of blade arms (5) Blade Attachment Hardware (16 Screws with Fiber Washers) Canopy assembly Mounting plate Ball/downrod assembly Switch housing Electrical Hardware (3 Plastic Wire Nuts) Coupling cover...
  • Page 6: Installing Your Fan

    Installing Your Fan Provide Strong Support Figures 1~3 are examples of different ways to Tools Required mount the outlet box. Phillips screwdriver, straight slot screwdriver, step ladder and wire cutters. Recessed Ceiling Outlet Box Mounting Plate Figure 3 Mounting Options Outlet Box Note: You may need a longer downrod to If there isn't an existing UL listed mounting box,...
  • Page 7: Hanging The Fan

    Hanging the Fan Align the holes at the bottom of the downrod Motor Wires with the holes in the coupling on top of the motor housing (Figure 6). Carefully insert the REMEMBER to turn off the power. Follow the Ball/Downrod clevis pin through the holes in the collar and Assembly steps below to hang your fan properly.
  • Page 8 Installing Fan to the Electrical Box UL Listed WARNING Outlet Box TO REDUCE THE RISK OF FIRE, ELECTRIC 120V SHOCK OTHER PERSONAL INJURY. Ceiling Wires MOUNT FAN ONLY TO AN OUTLET BOX OR Groove SUPPORTING SYSTEM MARKED ACCEPTABLE Mounting FOR FAN SUPPORT AND USE THE MOUNTING Bracket SCREWS PROVIDED WITH THE OUTLET BOX.
  • Page 9 Making the Electrical Turn wire nut connections upward, spreading SUPPLY CIRCUIT them apart so the green (ground) will be on one Connections side of the outlet box and the white, black and blue wire will be on the other side, and push Ground REMEMBER to disconnect the power.
  • Page 10 Finishing the Fan Installation Outlet Box Tuck connections neatly into ceiling outlet box. Ceiling Slide the canopy up to mounting bracket and place the key hole on the canopy over the screw on the Mounting Screws mounting bracket, turn canopy until it locks in place at the narrow section of the key holes. (Fig. 10) Bracket Align the circular hole on canopy with the remaining hole on the mounting bracket, secure by Canopy...
  • Page 11: Attaching The Fan Blades

    Attaching the Fan Blades CAUTION MOTOR IS SHIPPED WITH RUBBER PACKING MOUNTS TO PREVENT MOVEMENT DURING TRANSPORTATION. REMOVE RUBBER Motor PACKING MOUNTS FROM MOTOR ASSEMBLY AND DISCARD PRIOR TO ATTACH- ING BLADE ARMS. (FIG. 11) Attach blades to blade arm using the screws with fiber washers provided (Fig.
  • Page 12 Blade Balancing The following procedure should correct most fan wobble. Check after each step. Touching Ceiling Check that all blade and blade bracket screws are secure. Most fan wobble problems are caused when blade levels are unequal. Check this level by selecting a point on the ceiling above the tip of one of the blades.
  • Page 13: Installing The Light Kit

    Remove the lock ring from the socket by Installing the Mounting Installing the turning the lock ring clockwise until it unlocks. Plate Insert the glass into the glass holder and turn Light Kit the lock ring counter-clockwise to tighten the glass.
  • Page 14: Fan Without Light Kit

    Fan without Light Kit (Optional) CAUTION BEFORE STARTING INSTALLATION, DISCON- NECT THE POWER BY TURNING OFF THE CIRCUIT BREAKER OR REMOVING THE FUSE AT FUSE BOX. TURNING POWER OFF USING THE FAN SWITCH IS NOT SUFFICIENT TO PREVENT ELECTRIC SHOCK. Wire Connection Screws Plugs...
  • Page 15: Operating Your Fan

    Operating Your Fan NOTE Warm weather - (Counter-Clockwise direction) A downward air flow creates a cooling effect as WAIT FOR FAN TO STOP BEFORE REVERSING THE DIRECTION OF THE BLADE ROTATION. shown in Figure 19. This allows you to set your air conditioner on a higher setting without affecting your comfort.
  • Page 16: Care Of Your Fan

    Care of Your Fan Troubleshooting PROBLEM SOLUTION Here are some suggestions to help you maintain your fan. Fan will not start Check main and branch circuit fuses or breakers. Because of the fan's natural movement, some Check line wire connections to the fan and switch wire connections in connections may become loose.
  • Page 17: Specifications

    Specifications FAN SIZE SPEED VOLTS AMPS WATTS N.W. G.W. C.F. 0.20 1716 10.8 kgs 12.3 kgs 52” MED. 0.35 3419 2.41' (23.76 lbs) (27.06 lbs) HIGH 0.48 4884 These are approximate measures. They do not include Amps and Wattage used by the light kit .
  • Page 18: Warranty Information

    Hampton Bay Lifetime Limited Warranty (lifetime warranty on motor) The Hampton Bay warrants the fan motor to be free from defects in workmanship and material present at time IMPORTANT NOTE: of shipment from the factory for a period of lifetime after the date of purchase by the original purchaser.
